KHYD110 Electric Rock Drilling Rig

FOB Price

US$ 1000 - 10000 / Set

1 Set(Min. Order)

Port QINGDAO
Payment TermsT/T L/C

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	HUAXIA MASTER	Place of Origin	China
Type	Rotary Drilling Rig	Certification	ISO9001
After-sales Service Provided	Engineers available to service machinery overseas	Warranty	6 months
Weight	110KG	Power Type	Diesel
Usage	Coal	Condition	New

Product Description

1. Brief introductions of KHYD110 electric rock drilling rig

· The electric rock drilling rig can be fitted with drill stand, and can be drilled horizontally or upward in any direction.

· In order to prolong the service life of the drill bit and improve the working conditions of the operator, wet drilled water can be used to discharge the powder and screw blade drills can also be used for dry draining.

· In the operation of electric motor rock drilling rig, we only need to operate the handwheel, and the electric motor rock drilling rig can advance itself and return quickly.

2. Specifications of KHYD110 electric rock drilling rig

Model	Unit	KHYD110
Rated output power of motor	kw	5.5
Rated voltage of motor	v	380/660
Rated frequency of motor	hz	50
Rated current of motor	a	11.6
Motor speed	r/min	1440
Motor phase number		three phase communication
Rated working mode		continuity
Drilling speed	mm/min	280
Speed of return	m/min
Borehole diameter	mm	42-80（rock）
Hardness range	protodikonov`s scale of hardness	f<10
Maximum drilling depth	m	20（rock）
Weight of drilling rig (excluding runways, drill pipes, drills)	kg	110
Dimension (length * width * height)	mm	950460430
