Stainless Steel Johnson Water Well Screen, Deep Well Drilling Pipe
Quick Details
Place of Origin:
Hebei, China (Mainland)
-
Brand Name:
XINLU
Usage:
Liquid Filter
Type:
Filter Cylinder
Material:
Metal, Low Carbon,Low Carbon Galvanized,Stainless Steel etc.
Hole Shape:
Square
Filter Rating:
15%-70%
Thickness:
4-10 mm
Length:
2.9m,5.8m,or requirement, 2.9m or 5.8m in usual to fit container
Width:
60mm-426mm
Diameter:
2" 3" 4" 6" 8" 10" 12" 14" 16"
Slot size (mm):
0.5, 0.63, 0.75, 1.0,1.5mm in usual
End connection:
male/female threaded couplings or Welded rings
Application:
Kinds Filtration Industry
Shape:
Round Discs
Feature:
Heat Resistance
Key word:
water well screen
Certificate:
ISO
Supply Ability
Supply Ability:
1500 Piece/Pieces per Month
•Product advantages:
1.Lower pumping costs
Water well screen have more open area than other screen types,which lets more water enter more easily.This creates less drawdown inside the well reducing the energy demand on the pump.
2.Less pump wear
Properly designed screens prevent sand from entering the well,preventing abrasion of pump impellors.The low entrance velocity also reduces sand pumping and head loss.
3.Longer well life
Because water enters the well easily,it can move at a low velocity-0.03m/s or less (0.01ft/s).Higher velocities create higher pressure drop or head loss,allowing gases to pass out of the solution,leading to encrustation of the screen surface.
Continuous-slot screens provide more intake area per unit area of screen surface than any other type. For any given slot size, this type of screen has maximum open area.
•Our advantages:
Due to its high open area,our screens can be developed more effectively as more of the development energy can reach the formation.This ensures that more fine material is removed quickly as all the energy can be directed at the surrounding formation.
The continuous slot Vee-Wire screen is recommended in the following situations:
1.Formation comprised of small or fine particles
2.Water wells where gravel packs will be installed
3.Thin aquifers where maximum open area is required
