LJZ2-450X3700C Aluminum Profile Double Mitre Saw Machine
- 200 Set / Sets per Month
- Qingdao China window and door cnc
- T/T Credit Card
You May Like
-
LJJA-500 Aluminum Corner Connector Cutting Saw Machine
-
LJJA-500 Automatic Heavy Duty Aluminum Windows Corner Connector Cutting Saw
-
LXD-200 Aluminum End Milling Machine
-
LXDX-250x5 Aluminum End Milling Machine
-
LJGB-500 Heavy Duty Single Head Cutting Saw for aluminum profile cutting
-
Digital Display Double Head Cutting Machine LJGX-500 x 4200 for aluminum profile
Product Details
Brand Name | MMCNC | Model Number | LJZ2-450X3700C |
Wooden case or iron pallet into container
Product Description
Aluminum Profile Double Mitre Saw Machine
1. Feature
1.1 The machine is used for cutting of aluminum profile
1.2 Imported carbides blade is of accurate processing and high endurance
1.3 The two heads can work alone,can also work at the same time
1.4 To cut out a section of desired length and two end angles
1.5 Right head adopts motor drive
1.6 Two saw head can be manually switching angle,realize the -45 degrees,90 degrees,45
degrees angle cutting profile.
2. Technical Parameter
2.1 Input power:3.55kw
2.2 Power supply:380V/5Hz
2.3 Air pressure:0.5~0.8MPa
2.4 Motor rotary speed:2800r/min
2.5 Saw blade specification:φ450xφ30
2.6 Cutting angle:45°~90°~45°
2.7 Cutting length:680~3700mm
2.8 Cutting width x height:120 x 160mm
2.9 Overall dimension:4600 x 1300 x 1550mm
3.0 Weight about:770kg
3.Parameters:
Input Power | 3.55kw |
Power Supply | 380V/50Hz |
Working Pressure | 0.5-0.8MPa |
Rpm | 2800r/min |
Size of Saw Blade | φ450xφ30 |
Cutting Angle | -45°-90°-45° |
Cutting Range | 680-3700mm |
Cutting Width * Height | 120*160mm |
Dimension | 4600*1300*1550 |
Weight | 770kg or so |
4.DETAIL PHOTOS
Relevent Aluminum Machines:
5.Samples
l 1.One year warranty time, we can repair and replace parts for free in one year.
l 2.Technical support in 24 hours online, TM, Skype, E-mail, solving the relative questions in time.
l 3.Life time free maintenance service.
l 4.Free training course at our factory with professional engineers.
l 5.We provide the consumable parts at agent price when you need replacement.
l 6.Engineer available overseas.
