Product name:
1325 Light 4-axis Carousel Tool-changing CNC Processing Center
Product model:
Technical parameters
u M1325-4 ATC type 4-axis CNC processing center is equipped with bamboo hat-like tool magazine. All parts adopt internationally advanced products.
u Adopt Italy air-cooling high-power motorized spindle, and imported motor is adopted for the drive system.
u Vacuum table, with high absorption force, available for powerfully absorbing different sizes of materials.
u 4-axis linkage, available for side milling, drilling, cutting, and locking hole; and suitable for processing in large-size door factories and side-processing of special materials
u High-strength machine body with solid structure, going through aging and tempering treatment, and ensuring the gantry out of deformation and trembling permanently so reach high-precision processing
u With many models such as 1530-4ATC, 2030-4ATC and 2040-4ATC as options
u Fixture: Wooden door, cabinet, and panel-type, office and solid wood furniture, tables, chairs, doors and windows.
u Woodwork: Loudspeaker box, playstation cabinet, computer desk, sewing machine
desk, musical instruments
u Panel processing: insulating parts, plastic and chemical parts; PCB; inner body of motor car, bowling runway, stairs; compact grade laminate, epoxy resin, ABS, PP, PE and other carbon components.
u Decoration industry: Acrylic, PVC, fiberboard, artificial stone, organic glass, plastics, and engraving, milling and cutting of soft metal like copper and aluminum
Functions and features
Item No. |
Function |
Parameters |
1 |
Working dimension |
1300 X 2500 X 400mm X ±90° |
2 |
Positioning accuracy |
± 0.03/300mm |
3 |
Repositioning accuracy |
±0.01 mm |
4 |
Table |
Vacuum table |
5 |
Transmission |
X and Y racks, Z lead screw |
6 |
Max. operating speed |
20000mm/min |
7 |
Power of spindle |
Italy HSD air cooling 9.0KW |
8 |
Speed of spindle |
0-24000RPM |
9 |
Driving motor |
Imported motor |
10 |
Working voltage |
AC380V/50Hz,3PH |
11 |
Working Command |
G Code |
12 |
Operating system |
Taiwan Syntec Control System |
13 |
Software |
UG, powermill, and etc. |
