Single and Combination Mould Aluminum Window And Door Punching Machine
- 50 Set / Sets per Month
- qingdao
- T/T Credit Card
You May Like
-
Copy routing Drilling Machine CNC Lock Holes Making Machine for Milling Aluminum Profile
-
Aluminum Doors And Window Making Machine for Door Production Line
-
Punching Press Machine for Aluminium Profile
-
Aluminum Door and Window Corner Connector Automatic CNC Cutting Saw
-
Machine Used for Aluminum Corner Connector Profile Cutting
-
Aluminum Window CNC Double Head Cutting Saw
Product Details
Brand Name | DECALUMA | Place of Origin | Shandong, China | |
Model Number | LY2-160 | Certification | CE/ISO9001 | |
After-sales Service Provided | Overseas third-party support available | Warranty | 1 year | |
Weight | 1200KG, 1200Kg | Dimension(L*W*H) | 1550*770*1280mm | |
Voltage | 380V | Condition | New | |
Power(W) | 5.5KW | CNC or Not | Normal | |
Power Source | Hydraulic |
Product Description
Single and Combination Mould Aluminum Window And Door Punching Machine
Model: LY2-160
1. This machine is mainly matched with single and assembling die of aluminum window and door,it can finish all hole and notch punching and processing of different kinds of plain profile and thermal break extrusion, sliding or casement windows.
2. Applicable for installation of aluminum windows and doors and the punching processing of aluminum profiles.
3. Punching process, by changing processing position, various types profiles can be processed.
4.Two column can achieve stable punching,high efficient,low noise, free of pollution and high precision.
5. High hydraulic power and processing quality.
6. There are four pillars keeping working stability.
Power supply | Made to order |
Motor power | 5.5kw |
Motor rotational speed | 1620r/min |
Rated oil pump pressure | 16MPa |
Capability of oil box | 20L |
Press nominal pressure | 160KN |
Closing height | 140mm-280mm |
Punching travel | 60mm |
Contour dimension | 1550*770*1280mm |
Weight | 1200KG |
1.Sample service:
Our engineer is available to travel abroad, help the installation, maintenance and training staff.
2. Customized service:
Free industrial information, free investment analysis for windows, doors, and curtain wall project, free layout design for window, and door and curtain wall product line.
3.After sales service:
One year guarantee
Free adjustment
Free training to operation and maintenance workers
Provide quick supply of spare parts for window and curtain wall companies.
We support Trade Assurance on Alibaba, which is a free payment protection service for buyer regarding product quality and transaction security.
JINAN DEGA MACHINE CO.,LTD.(decaluma)is located in Jinan city, Shandong province, China, which is a professional exporter and manufacturer focusing on research,production and sale of aluminum profile processing machine.
Our Company is a specialized company that engaged in research,producing and sales of high quality aluminum profile processing machine and windows and door processing machine, we have Export &Import right.
2. When you can do if my machine have some problems?
1) We can send you free components to you if your machines are in guarantee time.
2) We can send our engineers to repair your machines
3. When can we arrange shipment?
We usually arrange shipment within 15 days after getting deposit,but customized machines should be more than 25 says
4. Are you trading company or manufacturer?
Manufacturer(OEM)
5. Quick details about our company
Company Name | JINAN DEGA MACHINE CO.,LTD. |
Year established | 2006 |
Address | No.389,TIANCHEN ROAD,JINAN CITY,250101 CHINA |
Business type | Manufacturer |
Product range | CNC Machining Centre, aluminum cutting machine, corner key cutting, end milling machine,punching machine,copy router, crimping machine, drilling and bending machine |
Product advantage | Using advanced solidworks design platform |
Management certificate | ISO9001,national patent |
Fair we attend | Shanghai and Beijing international windows show |
E-catalog | available |
MOQ | 1 set |
Payment terms | TT or L/C |
Shipping port | Qingdao port |
