Single Head Welding Machine
US$ 1,800 - 1,900
MOQ: 1 Parcel
Key Specifications
Get Latest Price
Brand Name:
Guangdong Jiahua Machines Corporation
Place of Origin:
Guangdong, China
Model Number:
SHD01-100
Payment & Shipping
Payment Methods:
Port of Shipment:
guangzhou
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Single Head Welding Machine Pvc Doors Windows Mechanical Pvc Door and Window Cnc Corner Cleaning MachineUS$ 1,250 - 1,300MOQ: 1 Parcel -
Single-head Variable-angle Welding Machine For Upvc Windows And DoorsUS$ 5.00 - 15.00MOQ: 1 Parcel
-
CNC Four-head Corner Combining MachineUS$ 5.00 - 15.00MOQ: 1 Parcel
-
Plastic Doors and Windows Welding Machine (Two-points)US$ 2,450 - 2,650MOQ: 1 Parcel
-
AUTOMATIC STEEL SCREW FASTENING MACHINEUS$ 15 - 15MOQ: 1 Piece
Brand Name
Guangdong Jiahua Machines Corporation
Place of Origin
Guangdong, China
Model Number
SHD01-100
Weight
260kg
Voltage
220V 50Hz
Power
1.2kw
Usage
This machine is used for PVC door and window welding processing with
Dimensions
960*900*1460mm
Welding Area
20~120mm
Product Description
Single head welding machine
Description
Description This machine is used for PVC door and window welding processing with variable angle ranging from 30~180º, It features programming control,pneumatic driving,reliable function,simple operation and convenient maintenance.The machine is made up of machine head.machine frame,electric controlling tank and material support etc,There are fixing machine,pressing machine and heating machine etc.
Working Air Pressure 0.5~0.8Mpa Air Consumption 50L/min Power Supply 220V 50Hz Total Power 1.2kw Welding height 20~120mm Max.width of profile welded ≤120mm Max.cut dimension of profile welded 330mm Outside Dimension 960*900*1460mm Weight(about) 260kg |
|
|
