PVC Door-Window 4-Corner Welding Machine With CNC SHP4-CNC-1800*3000
- qingdao
- T/T Credit Card
You May Like
-
PVC Profile Auto Water-Slot Routing Machine SCX02-2*60/pvc Upvc Window and Door Making Machine
-
PVC Door-Window High-Speed Corner Cleaning Machine With CNC HSC-F5
-
PVC Profile Double Mitre Saw
-
PVC Profile Single Head Cutting Saw
-
PVC Door-Window High-Speed Cleaning Machine With CNC
-
PVC Profile Sealed Cover Milling Equipment/pvc Upvc Window Door Making MachineSFX02-160
Product Details
| Brand Name | parker | Place of Origin | Shandong, China | |
| Weight | 3000KG | |||
| Voltage | 380V | Power | 10KW | |
| Usage | PVC window door welding | Frequency | 50HZ | |
| Dimensions | 5000*2100*2870mm | Welding Area | 380x420-1800x3000mm |
Product Description
Features:
◆ It is special equipment for processing PVC door and window; automatic achieving to welding rectangular PVC frame and fan. It is a new type we developed and has lead high level in China. Use CNC control system, imported MITSUBISHI servo motor and PLC; super touch screen control system, it easy to operate.
◆ Adopt different kind of profiles to achieve high accuracy automatic scale clamping angle; Adopt original installation import flat square guide rail, which can guarantee the precision of the heads when moves horizontally. Transmission adopts the original imported installation ball bearing master screw.
◆ The precision is extremely high so it can guarantee group angle quality. The servo controlling machines, servo motor, person-machine touching the contact surface are adopt the original imported installation of Japanese Mitsubishi system, and the increase assistance brake system.
◆ It is stable and efficiency. Adapt to three sides covering course, and have the function of crimping and positioning. Effectively ensure the dimensional accuracy of welding products, such as the shape and location accuracy and flatness.
◆ Welding tumor double overflow through the rational control, effectively increasing profile welding area and increasing 30% welding intension; meanwhile, to achieve the desired effect of cleaning up the angle joints prepared the necessary conditions. Achieve to welding a frame one time will greatly enhance the work efficiency.
Pre-Sales Service
* Inquiry and consulting support.
* Sample testing support.
* View our Factory.
After-Sales Service
* Training how to instal the machine, training how to use the machine.
* Engineers available to service machinery overseas.
PARKER Introduce
*PARKER Machinery Co.,LTD was founded in 2003,since the entry into the window door curtain wall machinery manufacturing field,peck with the best team and most stringent manufacturing standards,has been committed to the global supply of machinery and the best service.Today,with more than 300 employees,PARKER Industrial Park covers an area of 70000 m^2,Parker has become Chinese and even the world's window door curtain wall and insulating glass high-end machinery manufacturing base.
*PARKER products include aluminium,PVC window and doors machinery,aluminium curtain wall processing machinery,industrial aluminium processing machinery and insulating glass series production line machinery.
*PARKER machinery expotrs to the world more than 80 countries and regions,and has firstly established branches in USA,India,UAE,Brazil,has more than 15 patents.
*PARKER machinery are all passed through high standard European CE certification,American UL certification and Canadian CSA certification.
*PARKER manufacturing creates ecological management system of 9M that is unique and most proud of,and the human resources,raw materials,technology methods,environment,information etc. Have been ongoing ascension,and improves the overall quality and core competitiveness of parker.Customers around the world are actively popularize and apply it,benefit a lot from it.
*PARKER machine core parts procurement achieved internationalization,and established a cooperative partnership with ABBA,OMRON,SCHNEIDER,OPTIMA.
*PARKER people are always follow the core concept,it is "PARKER is developing with the world",it is PARKER peoples' strict implementation of ecological system of PAREKR and of "zero defect" stern pursuit,which makes the PARKER machine perfect implement unique global standard,achieves improvement value and sustainable innovation!
*PARKER machinery,leads the era of intelligence,create the strategy of globalization!
*PARKER machinery,contribution to the world culture of windows and doors!
PARKER Cooperative Partner
Q: Are you trading company or manufacturer ?
A: We are factory.
Q: Where is your factory located? Can I visit there?
A: Our factory is located in Jinan City, Shandong Province, China, near to Jinan and Qingdao. You are warmly welcomed to visit us!
Q: How does your factory do regarding quality control?
A: We have strict control in testing of raw material, production process and final process. Only qualified products can be sent out.And we have passed ISO,CE certificate.
Q: What you can do if my machines have problems?
A: a.We can send you free components to you if your machines are in guarantee time.
b.We can send our engineers to repair your machinesContact Us
