PVC Window Door Frame Welding Machine
- Qingdao Shanghai China
- T/T Credit Card
You May Like
-
Double Head Welding Machine for PVC Window Door Frame Used
-
Welding Machine for PVC Window Door Frame Used/UPVC Window Welding Machine
-
Single Head Cutting Saw Machine /PVC Window Door Frame Fabrication Machine
-
Upvc Double Head Cutting Machine / Pvc Window Fabrication Machine
-
Upvc Fabrication Equipment / Double Head Cutting Machine
-
Upvc Double Head Saw Cutting Machine for Windows / Upvc Window Fabrication Machine
Product Details
| Brand Name | PARKER | Place of Origin | Shandong, China | |
| After-sales Service Provided | Engineers available to service machinery overseas | Weight | 140kgs | |
| Voltage | 220-380V | Power | 4.5KW | |
| Frequency | 50HZ | Dimensions | 4500x1740x1100mm | |
| Welding Area | 400mm to 3500mm |
Product Description
PVC Window Door Frame Welding Machine
Description
FHW480 four head seamless welding machine is suitable for special shaped window welding like arch windows. It can weld and clean the corner at one time and is specially used for welding the colored window and door profiles. This four head PVC welding machine composes of four machine heads, machine frame, electric control tank and material supporting frame. In the press welding process of UPVC profiles, this four head seamless welding machine can clean the welding beadings on upper and bottom surface. It can also control the size of welding seam (the seam size is less than 0.2 mm) and make the corner be good-looking and of top grade. This four head PVC welding machine can achieve the whole welding processing individually.
Features
1. Our four head seamless welding machines feature reliable function and easy operation.
2. One of the machine heads can be used for welding processing with variable angles.
3. Parker four head PVC welding machines are famous for advanced technological equipment, tremendous technical strength and reliable product quality.
4. The four machine heads can be used individually, simultaneously or jointly at will.
5. This four head seamless welding machine is also installed with fixing mechanism, pressing mechanism and heating mechanism.
Technical Specifications:
Model | FHW480 Four Head PVC Welding Machine |
Type | Seamless |
Voltage | 220 V 50 Hz |
Total Power | 4.5 kW |
Air Pressure | 0.5 to 0.8 MPa |
Air Consumption | 80 L/min |
Profile Height | 20 mm to 100 mm |
Max. Profile Width | 120 mm |
Welding Size | 400 mm to 3500 mm |
Overall Dimension | 4500mm × 1740 mm × 1100 mm |
Weight of Four Head Seamless Welding Machine | 1400 kg |
Parker Machinery Co., Ltd is a leading supplier and exporter of door and window making machine in China.
We mainly provide aluminum profile Machine:
1)Aluminium window door frame machine :CNC cutting machine,
2) insulating glass processing machine.
3)PVC window and door machine,
4)3Axis,4Axis CNC Drilling and Milling Machine Center curtain wall equipment, and so on.
Complying with European standards, we always purchase main parts internationally.
Our machinery has passed CE and UL certifications.
They are exported to over120Countries and regions, such as North America, East Europe and the Middle East
1)Over 13 years factory experience in this line
Parker Machinery Co.,Ltd China. who established in 2003 year,we own 13years experiences,
We have a large group of good quality with good price parts supplier: Aluminum Window Door Making Machine,PVC Window door making machine, Insulating Glass Production Line, CNC milling and drilling machine center.They are stable and very cooperated due to our big factory strength.
2)Professional/Advance Production lines with professional workers!
4 Factory shope for our product which have been get patented Invented.and 24 hours work time for our customer
3).The stable annual output
The stable output was upon the stable quality,This can only be achieved through innovative research
and developments together with decades of experience on countless brewery projects all over the world.
4).Our factory workers and service team was very powerful and professional.
We always can meet your requirements upon our tech and service.
The large group of tech and service team will meet you around 24 hours.we have our professional
5).We have our own brand “PARKER"OEM/ODM acceptable
In the past 13ears,our own brand "PARKER"have high reputation among local and abroad.
we have our agent in Europe, South America,North America and Asia,
We will search more higher agent around the globe.
