PVC Window Variable Angle PVC Welding Machine
SHD01-120 single head any angle welding machine is also known as single head variable-angle welding machine or single-point any angle welding machine. This single head welding machine is mainly used for PVC, UPVC, plastic or vinyl profile welding for making windows and doors. With programming control and pneumatic drive system, it enjoys the features of high reliability, large processing range and easy operation. The two heads of this variable-angle welding machine can work individually or simultaneously.
Features
1. SHD01-120 single head welder is mainly made up of machine head, machine frame and electric controlling tank. There are also fixing machine, pressing machine and heating machine.
2. This variable-angle welding machine can be used for PVC door and window welding processing with variable angles ranging from 30 to 180 degree.
3. Parker single head welding machine features PC control, pneumatic driving, reliable function, simple operation and convenient maintenance.
4. Our company owns a professional technical team of first-class rich experience and well-trained technicians. Parker variable-angle welding machines have received a number of favorable comments from customers both home and abroad.
Technical Parameters
| Model | SHD01-120 Single Head Welding Machine |
| Voltage | 220 V 50 Hz |
| Total Power | 1.2 kW |
| Air Pressure | 0.5 to 0.8 MPa |
| Air Consumption | 50 L/min |
| Profile Height | 20 mm to 120 mm |
| Max. Profile Width | 120 mm |
| Overall Dimension | 960 mm × 900 mm × 1460 mm |
| Weight of Single Head Variable-Angle Welding Machine | 260 kg |
PARKER IS DEVELOPING WITH THE WORLD.
Parker was founded in 2003, since the entry into the window door curtain wall machinery manufacturing field, peck with the best team and most stringent manufacturing standards, has been committed to the global supply of machinery and the best service. Today, with more than 300 employees, Parker Industrial Park covers an area of 70000 square meter, Parker has become Chinese and even the world's window door curtain wall and insulating glass high-end machinery manufacturing base.
Q: How can I get the best machine for our business?
A: Just let us know your cutting material, size, thickness, and working area needed, we will suggest the most suitable machine and professional solution.
Q: When can we arrange shipment?
We usually arrange shipment in 15 days after getting deposit, but customized machines should be more than 25 days.
Q: This is my first time using this kind of machine, is it easy to operate?
A: Of course the machine is easy to operare. We will send you the English version user manual and install video which shows how to assamble and use the machine clearly, almost all the customers can operate the machine easily. No need to worry about this, after all, Parker will always be here to help!
Q: If the machine has problem in my place, how could I do?
A: Usually there won't be any problem under "normal use" as per the user manual. But in case you have any problem, our professional after-service team will provide you any support you need any time!
B.We can send you free components to you if your machines are in guarantee time.
C.We can send our engineers to repair your machines.
Q: This machine is not suitable for me, do you have more models available?
A: Sure, in order to meet different customers' different requirments, we reserched many other different machines.
