UPVC Window Machine for Auto 4 Point Welding
- Qingdao or any port of China
- T/T Credit Card
You May Like
Product Details
| Brand Name | Better | Place of Origin | Shandong, China | |
| Model Number | SHP4-CNC-3000G | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
UPVC window machine for auto 4 point welding
Model:SHP4-CNC-3000G
Production flow
This machine is the special equipment for the welding of plastic profiles and rectangle welding in a ringlet with
advanced technology, stability and compact structure.pneumatic driving and the imported complete line pain
gives the machine easy operation and high accuracy, The computer programming control enlarged there liability
and ensures the high efficiently,This machine is suitable for large volume production,The pneumatic driving
system uses the imported parts of excellent performance and longevity,The controlling part are imported
computer for industry the driving system uses the imported step by step motor and imported timing belt which
ensure the locating accuracy and longevity.
Working Air Pressure | 0.5~0.8Mpa |
Air Consumption | 200L/min |
Power Supply | As required |
Input Power | 11kw |
Welding Dimension Range | 300x300mm~1800x3000mm |
Welding Profile Height | 20~120mm |
Welding Profile Width | ≤120mm |
Outside Dimension | 5500x3500x1200mm |
Weight(about) | 3000kg |
Welding machines---One / two / three / four head
Cutting machines---One / two head
Water slot milling machine,Corner cleaning machine,V notch cutting saw,
Glazing bead cutting saw,End milling machine,Lock hole milling machine
