PA thermal break assembly machines for special aluminium profiles
- 10 Set / Sets per Month
- Qingdao
- T/T Credit Card
- PA thermal break assembly machines for special aluminium profiles
- Amachine thermal break profile assembly line-knurling machine
- thermal break profile assembly line-knurling machine
- Three-step High-efficient aluminium profile rolling machine-thermal break machine_Amachine
- Automatic High-efficient aluminium profile rolling machine-thermal break assembly machine
- CNC Thermal break assembly machines_rolling machine for special aluminium curtain wall_super high efficiency
Product Details
Brand Name: | Amachine | Place of Origin: | Shandong, China | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
PA thermal break assembly production line
GYJB-01 Rolling Machine
Applications:
This rolling machine is to combine thermal barrier strip or plastic profile with aluminum profiles to make thermal break aluminum profile, suitable for rolling of aluminum and wood material composite profiles.
Features:
1, Eight sets of hardened rolling discs and rubber roller are electrically controlled for fast change of profiles.
2, Eight rolling discs controlled by separate driving force guarantee stable rolling, high speed, and high efficiency.
3, Vertical and horizontal distance between each pair of rolling discs is adjustable for different sizes of profiles.
4, Step-less speed regulation. Taiwan HIWIN linear rail, Schneider electrical appliance, and precision screws are adopted.
5, Suitable for rolling of aluminum and wood material composite profile, one-side thermal barrier strip profile,etc.
Technical data:
Model | GYJB-01 |
Power supply | 380V/50Hz |
Total power | 4.73Kw |
Two-axis control | Rolling discs and upper rubber rollers |
Rolling disc diameter | 240mm |
Two rolling discs(one pair) distance | 0-50mm |
Rolling disc height regulating range | 0-80mm |
Max rolled section | 250x250mm (WxH) |
Rolling speed | 0-60m/min |
Overall dimension | 1960x1050x1550mm |
Weight | 1500kg |
