Warranty period is 24 months after BL time
Laser Cutting Machine Name: FM-3D 10w 20w 30w 50w 3d dynamic fiber laser holographic marker marking machine
Laser Cutting Machine Model: FM-3D
10w 20w 30w 50w 3d dynamic fiber laser holographic marker marking machine
Feature:
- The 3D dynamic focus laser marking machine is suitable for the demand of three-dimensional surface laser processing work. This technology makes the 3D laser marking simple and brings more laser solution.
- High-precision three-dimensional positioning technology, high-speed focusing and scanning system, laser beam fundamental mode, short pulse, high peak power, and high repetition rate provide customers with the ideal marking effect;
- Three-dimensional graphics processing technology has friendly operation interface and is suitable for dxf, plt, cnc, step, iges and other formats;
- High photoelectric conversion rate, long machine life and easy maintenance;
- Marking speed is improving the processing efficiency greatly.
Application:
It can Mark graphics and text on the Metal surface, stainless steel, aluminum alloy, hard plastic, leather.
Case:
3D dynamic focus laser marking machine is suitable for laser marking of various metal or non-metal products with three-dimensional surface. It is widely used in mobile phone manufacturing, three-dimensional circuit, medical equipment, mold, 3C electronics, auto parts, electronic communication and other industries.
Marking Effects:
|
|
|
10w 20w 30w 50w 3d dynamic fiber laser holographic marker marking machine
Technical Parameters
Parameters | Model | FM-3D-20W | FM-3D-30W | FM-3D-50W |
Laser Parameters | Laser Type | fiber-optic laser | fiber-optic laser | fiber-optic laser |
Average Output Rate | 20W | 30W | 50W | |
Wave Length | 1064nm | |||
Pulse Repetition Frequency | 20-100KHz | 20-100KHz | 50-100KHz | |
Beam Quality | <1.2 | <1.2 | <1.2 | |
Cooling Type | Air Cooling | Air Cooling | Air Cooling | |
Marking Parameters | Marking Type | XYZ Three-axis Dynamic Focus | ||
Marking Scope | (300*300/200*200)*80mm (According to demand) | |||
Focus Range | ≤±30mm | |||
Max. Line Speed | ≤7000mm/s | |||
Max. Flat Marking Speed | 350 Characters/S | |||
Resolution Ratio | 0.001mm | |||
Repeated Position Accuracy | 0.003mm | |||
| Min. Line Width | 0.01mm | ||
| Min. Character Height | 0.1mm | ||
Whole Machine Parameters | Marking Environment | Temperature: 0~35℃; humidity: ≤90% | ||
Power Supply | Single Phase AC220V 50Hz 10A | |||
Whole Machine Power Rate | 0.5Kw | |||
Overall Dimension | 1240mmX800mmX1550mm | |||
10w 20w 30w 50w 3d dynamic fiber laser holographic marker marking machine
Scanning Galvanometer
10w 20w 30w 50w 3d dynamic fiber laser holographic marker marking machine
Application Industry
10w 20w 30w 50w 3d dynamic fiber laser holographic marker marking machine
Customized Attachment
Chuck Rotary for tube and pipe
Rotary Device for LED Light and related products
10w 20w 30w 50w 3d dynamic fiber laser holographic marker marking machine
Package
- Our senior engineer is available to travel aboard, help the installation, maintenance and training staff.
- We have our own spare parts warehouse for window door machines and insulating glass machines.
- We can reply for every customers within 24 hours.
- By offering this support, we make sure the cutomer start the business smoothly, to realise win-win cooperation.
- CCI always looking for long term cooperaion, not one time deal.
Company Introduction
CCI Group creates and develops the high quality fiber laser cutting machines, laser cutting and engraving machines, laser marking machines and window Glass Machines with 25 years hard working. Our aim is the best manufacturer of laser machines from China.
Attaching much importance to quality and taking management and technology development as the impetus, CCI Group tacks the culture of operation excellence, and has obtained ISO9001-2000 edition and CE Qualification successively. So far CCI Group has more than thirty offices around China, and has built many foreign office, such as in USA, Kazakstan, India, Vietnam etc.
Now CCI Group has become the all-around equipment manufacturer, producing more than one hundred kinds products, and is mainly engaged in four series: Fiber Laser Cutting Machines, Laser Cutting and Engraving Machines, Laser Marking Machines and Window Glass Aluminum Machines.
We would like to expand our cordial cooperation with you for better future.
CCI is the best choice you can choose.
A. Question: What kind of our company is CCI?
Re: CCI is laser cutting and engraving machine, window machines and insulating glass machines manufacturing expert since year 1991. We passed CE european standard on year 2002.
B. Question: How is 10w 20w 30w 50w 3d dynamic fiber laser holographic marker marking machine guarantee?
Re: b1. 10w 20w 30w 50w 3d dynamic fiber laser holographic marker marking machine warrenty period is 24 months after BL time;
b2.12 hours technical support feedback;
b3. Own machining factory, which can control the spare parts quality at high quality;
b4. Own accessories warehouse and user can enjoy the agent price.
C.Question: How is delivery time?
Re: We can delivery the machines within 7 days if we have the machines in stock.
The common machine fabricating time is 5-7 days and CNC machine fabricating time is about 25-45 days.If you have customized products, the delivery time will be given after confirmation.
D. Question: How is payment?
Re: 50% of amount as deposit and the balance should be paid by T/T or LC at sight before seller delivery the machines to loading port.
E.Question: How is our package?
Re: Wooden Pallet/ Wooden Case. In order to ensure high quality products precision, the perfect package is necessary.
F. Question: Why is price higher than other supplier?
Re: f1. We have our own machining factory and the high quality technical quality is our aim;
f2. All the electric parts and pneumatic parts are high quality. Most of them are imported from european and american market;
f3. Most of fabricating worker has more than 10 years working time. Their fabricating work is professional and salary is higher;
f4. Our warrenty period is 36 months after BL time. It can support the new comer client going well in the beginning time.
