Aluminum Window Profiles Curtain Wall Notching Saw
US$ 23,599 - 27,690
1 (Min. Order)
- T/T Credit Card
You May Like
-
Notching Aluminium Window End Milling Machine for Aluminum Curtain Wall
-
Holes 3 Axis Cnc Curtain Wall Aluminum Machining Center Machine
-
Holes Milling Drilling Tapping Aluminum Profile Curtain Wall Machining Center
-
Aluminium Curtain Wall Aluminum Window Machinery Cnc Double Head
-
Aluminum Window Door Holes Multi Spindle Drilling Machine
-
Human-machine Friendly Interface Mini Cnc Milling Machine With Tool Changer Drilling/ Tapping/milling Aluminum Profiles
Product Details
| Brand Name | FEIDA |
Product Description
Product Description
Product Application
--For milling end surface of aluminum and PVC profiles
--Cooling spray device
--With adjustable safety cover
--Showing angle on high precision digital display screen
--Good at milling varied end surfaces and processing multiple profiles within one clamping time.
--Auto feeding by hydro-pneumatic cylinder, and cutting with large stroke up to max. 800 mm.
--Positioning device.
Main Specification
1) Max. height of profile: 200 mm
2) Power supply: 38V 50Hz
3) Machine power: 2.2X2 kw
4) Rotational speed of spindle: 2800 rpm
5) Feeding-to-cutting travel 800 mm
6) Max. cutting blade diameter: Φ500 mm
7) Cutting blade aperture: Φ30 mm
8) Max. cutting depth: 200 mm
9) Angle range on horizontal: 25°-25°
10) Angel range on vertical: 25°-45°
11) Pneumatic working pressure: 0.6-0.8 MPa
12) Air consumption: 0.2 cubic m/min.
13) Dimensions: 2540×1300×1500
14) Weight: 500 kg
Notching Precision
1) Verticality of milling surface: 0.15 mm (100x100mm section)
2) Planenes of milling surface: 0.15 mm (100 x100mm section)
3) Roughness of milling surface: Ra 12.5 µm
--Cooling spray device
--With adjustable safety cover
--Showing angle on high precision digital display screen
--Good at milling varied end surfaces and processing multiple profiles within one clamping time.
--Auto feeding by hydro-pneumatic cylinder, and cutting with large stroke up to max. 800 mm.
--Positioning device.
Main Specification
1) Max. height of profile: 200 mm
2) Power supply: 38V 50Hz
3) Machine power: 2.2X2 kw
4) Rotational speed of spindle: 2800 rpm
5) Feeding-to-cutting travel 800 mm
6) Max. cutting blade diameter: Φ500 mm
7) Cutting blade aperture: Φ30 mm
8) Max. cutting depth: 200 mm
9) Angle range on horizontal: 25°-25°
10) Angel range on vertical: 25°-45°
11) Pneumatic working pressure: 0.6-0.8 MPa
12) Air consumption: 0.2 cubic m/min.
13) Dimensions: 2540×1300×1500
14) Weight: 500 kg
Notching Precision
1) Verticality of milling surface: 0.15 mm (100x100mm section)
2) Planenes of milling surface: 0.15 mm (100 x100mm section)
3) Roughness of milling surface: Ra 12.5 µm
Certifications
Detailed Images
STRONG STRUCTURE
GOOD MOTOR
CUTTING DRAWING
PERFECT PRODUCT
Our Service
Pre-Sales Service
* Inquiry and consulting support.
* Sample testing support.
* View our Factory.
After-Sales Service
* Training how to instal the machine
* Training how to use the machine.
* Engineers available to service machinery overseas.
Welcome To Visit Us
Packing & Delivery
Related Products
Products Name with link
91.8% Response Rate
Products Name with link
91.8% Response Rate
Products Name with link
91.8% Response Rate
FAQ
Q: If I make Aluminum window and door, how many basic machines do i need?
A: Double head cutting saw ,Lock hole copy milling machine,End milling machine,
Automatic Corner connector automatic cutting saw,Single head Corner Crimping machine.
Q: How can I get the best machine for our business?
A: Just let us know your cutting material, size, thickness, and working area needed.
we will suggest the most suitable machine and professional solution.
A: Just let us know your cutting material, size, thickness, and working area needed.
we will suggest the most suitable machine and professional solution.
Q: This is my first time using this kind of machine, is it easy to operate?
A: Of course the machine is easy to operare.
A: Of course the machine is easy to operare.
We will send you the English version user manual and install video which shows how to
assamble and use the machine clearly, almost all the customers can operate the machine
easily.
Don't worry about this. FEIDA will always be here to help!
Don't worry about this. FEIDA will always be here to help!
Q: If the machine has problem in my place, how could I do?
A: Usually there won't be any problem under "normal use" as per the user manual.
But in case you have any problem, our professional after-service team will provide you any
A: Usually there won't be any problem under "normal use" as per the user manual.
But in case you have any problem, our professional after-service team will provide you any
support you need any time!
B: We can send you free components to you if your machines are in guarantee time.
C: We can send our engineers to repair your machines.
C: We can send our engineers to repair your machines.
Q: This machine is not suitable for me, do you have more models available?
A: Sure, in order to meet different customers' different requirments, we reserched many other
A: Sure, in order to meet different customers' different requirments, we reserched many other
different machines.
Q: When can we arrange shipment?
A: We usually arrange shipment in 15 days after getting deposit, but customized machines should be more than 25 days.
A: We usually arrange shipment in 15 days after getting deposit, but customized machines should be more than 25 days.
Q: What services can provide in your company?
A: Two years guarantee
B: Free adjustment
C: Free training to operation and maintenance workers.
D: Free industrial information
E: Free investment analysis for windows, doors and curtain wall project.
B: Free adjustment
C: Free training to operation and maintenance workers.
D: Free industrial information
E: Free investment analysis for windows, doors and curtain wall project.
F: Free layout design for windows,doors and curtain wall production lines.
G: Provide follow-up service, regular maintenance and lifetime service for our machines sold.
H: Provide technical support including pressure design and caculation for window and curtain
G: Provide follow-up service, regular maintenance and lifetime service for our machines sold.
H: Provide technical support including pressure design and caculation for window and curtain
wall companies.
I: Provide quick supply of spare parts for window and curtain wall companies.
I: Provide quick supply of spare parts for window and curtain wall companies.
