SANY Brand 6cbm/8cbn/10cbm/12cbm Cement Concrete Mixer Truck
| Overall Parameters | Items | SY306C-6 | |
| Gross Weight | kg | 11000 | |
| Full Load Weight | kg | 32200 | |
| Dimension(L*W*H) | mm | 8030×2550×3700 | |
| Wheel Base | mm | 3025+1300 | |
| Min. Ground Clearance | mm | 240 | |
| Min. Turning Diameters | mm | 16 | |
| Fuel Consumption | L/100km | 35 | |
| Bore*Stroke | mm | ψ112×130 | |
| Displacement | L | 7.684 | |
| Rated Power/Rev Speed | KW/rpm | 202/2200 | |
| Max. Torque/Rev Speed | N.m/rpm | 1000/1500 | |
| Emission Standard | State Ⅲ | ||
| Drum | Geometric Capacity | m3 | - |
| Mixing Capacity | m3 | 6 | |
| Drum Obliquity | ° | - | |
| Feeding Speed | m3/min | - | |
| Discharge Speed | m3/min | - | |
| Discharge Residual Rate | % | ≤0.5% | |
| Slump Scope | mm | 50-210 | |
| Water Tank Capacity | L | 450 | |
| Oil Pump | - | ||
| Chassis | Engine | Weichai WP10.270E2 | |
| Gear Box | - | ||
| Front Axle | 5T | ||
| Middle, Rare Alex | 2*10T | ||
| Cab | SANY CB318 | ||
| Tyre | 10.00R20 | ||
| Brake | mm | Frontψ400*150, Frontψ410*220 | |
| Air Cylinder | L | 2*45 | |
| Fuel Tank | L | 200 | |
Sany truck mixer SY306C-6 with 6 cubic meter mixing capacity is equipped with ultra-high strength integrated auxiliary frame, ensuring its stability and high strength. The 6 cubic meter truck mixer can adapt to varied harsh conditions and improves its service life.
Specialized Cab
Safe and Secure
The specially designed cab is made using the newest robotic welding techniques and complies with the strictest front collision and top pressure regulations.
The instrument panel, mirror placement and overall design contribute to a field of view unparalleled in the industry.
Built for the Driver
The four point shock absorbing mounting, double layer door sealing, and noise reduction technology built into the cab help reduce driver fatigue during those long days on the job.
The interior trim of red and black exudes a sports car feeling to reduce visual monotony. Bluetooth technology with steering wheel controls allows hands free use of mobile devices (where permitted) to maintain contact with coworkers.
Attractive Styling
The modern European/American styling of the cab accents gives a car like feel.
The trim, instrument panel, and seats are of high quality materials.
Energy-saving Technology
The engine dual power mode, coupled with the unique intelligent transmission's power matching technology results in a 10% fuel savings.
Leading-edge Steering Technology
The large displacement power steering pump reduces operator effort by 40%.
Optimizing chassis geometry and front axle steering angle reduces the turning circle by 15%.
Anti-buildup Technology
The three section blade provides an efficient discharge angle.
The flushing device, an innovative front taper and ball-crown connecting structure are installed at the rear taper, in order to clear stagnant aggregate from the dead space, and to prevent aggregate from piling up at front and rear tapers. Due to this, the residual rate at the discharge port declines to 0.4%.
Smart Operating Technology
Each truck is equipped with a GPS system, which boasts five functions including truck monitoring, record/playback, alarm reporting, truck management, statistics and analysis.
With this information you can keep abreast of the mixer truck's location, maintenance items, discharge, etc.
Maintenance Tips
Dashboard mounted monitor provides maintenance alarms for the truck's key components such as engine, axle, and transmission in order to facilitate maintenance scheduling.
