43m Liug ong Hydraulic Reed HDL5330THB43 Concrete Pump
Double Logarithmic Variable Pitch Helical Mixer Blade: which enables higher charing and discharging speed and even mixing, eliminates segregation of concrete and is suitable for the transportation of both dry and wet materials.
New T-shape Blade technology. It is made of hard-wearing alloy steel, and thus protects the mixer blades from abrasion, extends the service life of the agitator drum, and enhances mixing performance.
The geometric capacity of the agitator drum is very large and the filling rate is low, thus guaranteeing more mixing space. The small inclined angle and low center of gravity help reducing the possibility of turning-over of the truck.
Closed loop hydraulic system and constant hydraulic oil temperature controller. Key hydraulic accessories including: Hydraulic plunger pump, adjuster mechanism with servo, hydraulic motor, and planetary reducer, all of which are manufactured in world-known brands with stable and reliable performances.
Multi-outlet washing design of which the cleaning requirements are met with the three fixed pipes for washing the agitator drum, charging hopper and discharging hopper respectively, and another flexible water outlet.
Three-point operation system: One in the cab to allow control of the agitator drum, to turn forward and reverse, and to perform the “feed”, “discharging”, “agitate” and “stop” functions. Two at the rear with one operation handle at each side to perform “charge”, “accelerate”, “discharge”, “agitate” and “stop”, all of which are interlocked.
Max. size aggregate |
mm |
40 |
Max. concrete pressure(L/H) |
MPa |
7/12 |
Hydraulic system pressure |
MPa |
32 |
Main hydraulic pump displacement |
ml/r |
190 |
Concrete cylinder bore & stroke |
mm |
Φ230×1800 |
Main hydraulic cylinder stroke |
mm |
1800 |
Concrete valve type |
/ |
S-Valve |
High/Low pressure |
/ |
AUTO |
Hydraulic tank capacity |
L |
400 |
Hopper charging height |
mm |
≤1500 |
Hopper capacity |
m3 |
0.7 |
Water tank capacity |
L |
285 |
Concrete slump |
mm |
120-230 |
Concrete pipeline bore |
mm |
Φ125 |
Max. horizontal reach |
m |
19.1 |
Max. pumping depth |
m |
12.2 |
Boom unfolding height |
mm |
6750 |
Boom unfolding angle |
(°) |
90/180/256 |
Section lenght |
mm |
7300/5950/5910 |
Slewing range |
(°) |
±365 |
Outrigger longitudinal span |
mm |
5510 |
Front outriggers transverse span |
mm |
4880 |
Rear outriggers transverse span |
mm |
2280 |
Chassis engine power |
kW/hp |
228/310 |
Emission stage |
CHINA IV |
|
Running speed |
km/h |
≤85 |
Min.turnning radius |
m |
8.8m |
Approach & Departure angle |
(°) |
20.5/10.5 |
