Product Details
| Brand Name | SANY | Place of Origin | Hunan, China | |
| Certification | ISO CE | |||
| Warranty | 1 Year | Weight | 27800kg | |
| Dimension(L*W*H) | 6730x2100x2600mm | Power Type | Diesel | |
| Condition | New |
Product Description
construction machinery stationary 30 m hydraulic concrete pump
Product Description
Length
10650 mm
Width
2500 mm
Height
3700 mm
Empty weight
19000 kg
Boom & Outrigger
Vertical reach
30.1 m
Horizontal reach
26.5 m
Reach depth
15.2 m
Unfolding reach
9.6 m
1st section-Length
7676 mm
1st section-Articulation
89°
2nd section-Length
6090 mm
2nd section-Articulation
180°
3rd section-Length
6100 mm
3rd section-Articulation
245°
4th section-Length
6635 mm
4th section-Articulation
230°
Rotation
±360°
Outrigger spread L-R-Front
5850 mm
Outrigger spread L-R-Rear
5420 mm
Pumping System
Output (Low/High-pressure)
120 m³/h
Pressure (Low/High-pressure)
6 Mpa
Max. strokes per minute (Low/High-pressure)
30 times/min
Delivery cylinder diameter
230 mm
Stroke length
1600 mm
Hydraulic system
Open
Hydraulic system pressure
32 Mpa
Hydraulic tank capacity
320 L
Water tank capacity
400 L
Pipe size
125 mm
End hose length
3 m
End hose diameter
125 mm
Chassis
Chassis model
ZZ5207M521GD1
Engine model
MC07.24-40
Engine power
176/2300 kW/rpm
Emissions
Tier4
Fuel tank capacity
300 L
Displacement
6.87 L
Max.speed
80 km/h
Brake distance
≤10/30m/km/h
