5 Ton Small Wheel Loader for Sale From Famous Brand
US$ 110,000 - 110,000
MOQ: 1 Unit
Key Specifications
Get Latest Price
Brand Name:
SEM
Place of Origin:
Guangxi, China
Type:
Front Loader
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai Port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Chinese XE470C 2.2CBM Bucket 47 Ton Large Crawler Excavators for SaUS$ 21,000 - 21,000MOQ: 1 Unit -
Chinese Brand New XE335C 33 Tons Heavy Crawler Excavator Machine For SaleUS$ 139,000 - 139,000MOQ: 1 Unit
-
Best Price XE470C 47 Ton Large Crawler Excavators Long Boom for SaleUS$ 21,000 - 21,000MOQ: 1 Unit
-
Chinese 47 Ton XE470C China Crawler Excavator for SaleUS$ 21,000 - 21,000MOQ: 1 Unit
-
47 Ton XE470C 2.2CBM Bucket Excavator Parts Spare for SaleUS$ 21,000 - 21,000MOQ: 1 Unit
Brand Name
SEM
Place of Origin
Guangxi, China
Type
Front Loader
Certification
CE ISO
Warranty
1 Year
Condition
New
Dimension(Long * Breadth * High)
8110*3000*3508mm
Moving Type
Wheel Loader
High Quality SEM Brand 5 ton Capacity Wheel Loader for Sale
Please Contact
Name: Aring Zhou
Mobile/Wechat/Whatsapp: +86-15855426352
Product Description
POWER TRAIN
- Engine C7.1 ATAAC Stage IIIA/Tier 3
- Torque converter
- Transmission, automatic, power shift (4F/3R), kick down function, overspeed protection
- Brakes, full hydraulic enclosed wet disc
- EIMS (Engine Idle Management System)
- Fan, radiator, electronically controlled, hydraulically driven, temperature sensing, on demand
- Filter, fuel primary/secondary/tertiary
- Fuel/water separator
- Filters, engine air, primary/secondary
- Fuel priming pump (manual)
- Muffler, sound suppressed
- Radiator, unit core (9.5 fpi) with ATAAC
- Starting aid, glow plugs
- Switch, transmission neutralizer lockout
HYDRAULICS
- Load sensing implement system pilot operated
- Dedicated load sensing steering pump
- Dedicated brake and fan gear pump
ELECTRICAL
- Alarm, back up/main disconnect switch
- Alternator (115 amp, brush type)
- Batteries, maintenance free (2×900 CCA)
- Ignition key; start/stop switch
- Lighting system, halogen (6 total): Four (4) halogen work lights Two (2) halogen roading lights
- Starting and charging system (24 volt)
- Starter, electric (heavy duty)
Main Parameters
| Net Power - ISO 9249 | 151.0 kW |
| Engine Model | C7.1 |
| Bore | 105.0 mm |
| Stroke | 135.0 mm |
| Displacement | 7.01 l |
| Maximum Gross Power - 2,000 rpm - ISO 14396 | 171.0 kW |
| Maximum Gross Torque - 1,400 rpm | 1020.0 N·m |
| Maximum Net Torque - 1,300 rpm | 931.0 N·m |
| Rated Gross Power - 2,200 rpm - ISO 14396 | 168.0 kW |
| Rated Net Power - 2,200 rpm - ISO 9249 | 151.0 kW |
| Operating Weight | 18676.0 kg |
OPERATING SPECIFICATIONS
| Bucket Capacities | 2.5 m3 to 4.4 m3 (3.3 yd3 to 5.75 yd3) |
| Breakout Force | 147.0 kN |
| Note (1) | **Compliance to ISO (2007) 14397-1 Sections 1 thru 5. |
| Note (2) | *Full compliance to ISO (2007) 14397-1 Sections 1 thru 6, which requires 2% verification between calculations and testing. |
| Static Tipping Load - Full 40° Turn - ISO 14397-1* | 10503.0 kg |
| Static Tipping Load - Full 40° Turn - Rigid Tires** | 11197.0 kg |
Product Image
