Home > Products > Earthmoving Machinery > Small Loader Changlin 5 Tons Wheel Loader With Rock Bucket
Small Loader Changlin 5 Tons Wheel Loader With Rock Bucket
US$ 46,900 - 53,000
/ Unit
1 Unit(Min. Order)
- Shanghai port
- T/T Credit Card
You May Like
Product Details
| Brand Name | CHANGLIN | Place of Origin | Jiangsu, China | |
| Model Number | 955 | Type | Front Loader | |
| Certification | CE ISO | After-sales Service Provided | Engineers available to service machinery overseas | |
| Warranty | 1 Year | Condition | New | |
| Dimension(Long * Breadth * High) | 7920*2800*3500mm | Moving Type | Wheel Loader | |
| Rated Load | 5000KG |
Product Description
small loader changlin 5 tons wheel loader with rock bucket
Contact way
Sales Manager
Alisa Wang
Newindu E-Commerce (Shanghai) Co.,Ltd.
Add: Suite 1326, Fortune Times Tower, No. 1438 North Shanxi Road, Shanghai, China
Tel: +86-21-62770109 Fax: +86-21-62120109
Mobile / Whatsapp/ Wechat/skype: +86-18616224775
Add: Suite 1326, Fortune Times Tower, No. 1438 North Shanxi Road, Shanghai, China
Tel: +86-21-62770109 Fax: +86-21-62120109
Mobile / Whatsapp/ Wechat/skype: +86-18616224775
Product Description
small loader changlin 5 tons wheel loader with rock bucket
| 1 | Bucket Capacity | 2.8~4.5m3 |
| 2 | Rated Load | 5000KG |
| 3 | Max.digging force | 160KN |
| 4 | Max.traveling force | 150KN |
| 5 | Operation weight | 16500KG |
| 6 | Overall Dimension | 7920x2800x3500MM |
| 7 | Engine Model No | WD10G220E23 |
| 8 | Rated Power | 162KW |
| 9 | Rated Speed | 2200r/min |
| 10 | Min. Fuel Consumption | ≤210g/kw.h |
| 11 | Max.Torque | 900N.m |
| 12 | Shifts(forward/reverse) | F2/R1 |
| 13 | Forward Traveling Speed | 0~12.1km/h 0~37.4km/h |
| 14 | Reverse Traveling Speed | 0~16.5km/h |
| 15 | Max. grade ability | 30° |
| 16 | Steering angle | ±38° |
| 17 | Min. steering radius | 5970mm |
| 18 | Dumping clearance | 3050mm |
| 19 | Dumping reach | 1107mm |
| 20 | Displacement of redirector | 1000ml/r |
| 21 | Operation pressure | 146Mpa |
| 22 | Lifting time | 6.2s |
| 23 | Lowering time | 3.8s |
| 24 | Dumping time | 1.8s |
| 25 | Standard tyre | 23.5-25-16PR |
| 26 | Tyre pressure | 0.274-0.294Mpa |
