Hot Sale 5t Wheel Loader Front End Loader ZL50GN
- Shanghai
- T/T Credit Card
You May Like
Product Details
| Brand Name | Newindu | Place of Origin | Jiangsu, China | |
| Type | Front Loader | Certification | CE ISO | |
| Warranty | 1 Year | |||
| Condition | New | Dimension(Long * Breadth * High) | 8165*3016*3485mm | |
| Moving Type | Wheel Loader |
Product Description
Hot Sale 5t Wheel Loader front end loader ZL50GN
Strong structure
Heavy load for the rocky condition; the working device and front and rear frame feature thick board of high strength, reasonable distribution and strong carrying capacity.
The large rock bucket with capacity of 3.0m³ is improved in terms of the work efficiency and adaptation. The bucket teeth adopt the structure of toothholder and sleeve. The cutting blade and bucket edge are equipped with protection device, featuring excellent abrasion resistance and shock resistance.
Excellent performance
The strong breakout force of 17 ton and strong traction of 17.5 ton ensure that the machine could adapt to various tough condition.
Reliable operation: with the long wheelbase of 3300mm and long machine body of 8185mm, the machine is ahead in the industry in terms of the operation reliability.
Quick action: the total time of three devices is only 10.3s, and the speed is 11.5 km/hour during the operation.
Experienced drive parts
Famous brand engine; The machine adopts the latest planetary transmission with multiple unique technologies, featuring high reliability and strong adaptation to heavy load; the reinforced drive shaft provides more reliable drive; the powertrain assembly made by could provide the powerful guarantee for the machine to operate efficiently and reliably.
Comfortable and safe driving space
Provide the best operation environment for the user with the design concept of the people oriented.
•The luxurious cab features large space and wide visibility.
•Elegant adjustable instrument panel and comfortable operation.
Convenient maintenance
Convenient and practical maintenance guarantees the service life of each part to improve the usage economics of the machine.
The hood adopts the large side door of sliding upward, featureing large opening angle, and more convenient for access.
Bucket | ZL50G |
Standard bucket capacity | 3.0M3 |
Rated load | 5000kg |
Rated time | 6 secretary |
Total cycling time | 11secretary |
Max.drawing force | 145Kn |
Max.breakout force | 170Kn |
Articulation angle | 35. |
Min.turn radius | 6400mm |
Climb ability | 28. |
Wheel base | 3300mm |
Tread | 2200mm |
Dumping clearance | 3090mm |
Dumping reach | 1130mm |
L×W×H | 8110×3000×3508mm |
Operating weight | 18t |
Clamp type | |
Min.clamping diameter | φ450/φ800mm |
Dumping clearance | 3230mm |
Dumping reach | 1845mm |
L×W×H | 8414×2800×3460mm |
Operating weight | 18t |
