High Quality Mechanical Truck Crane Zoomlion QY55 Price List

Name: High Quality Mechanical Truck Crane Zoomlion QY55 Price List
Brand: Zoomlion
Availability: InStock

FOB Price

US$ 140,000 - 180,000 / Unit

1 Unit(Min. Order)

Port Shanghai
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	Zoomlion	Certification	ISO CE
Warranty	1 Year
Application	Construction	Condition	New
Span	10.8m	Rated Lifting Moment	2009kN/m
Rated Loading Capacity	55ton	Max. Lifting Height	59.5m

Product Description

High quality mechanical truck crane Zoomlion QY55 price list

Please Contact

Steven Zheng

Newindu E-Commerce (Shanghai) Co.,Ltd.
Add: Suite 1326, Fortune Times Tower, No. 1438 North Shanxi Road, Shanghai, China
Mobile / Whatsapp/ Wechat: +86-13063433538

Email: Steven at
Web:

Product Description

Continuously overall promotion makes our lifting capacity of crane be improved once and once again.
43 m main boom , two section jibs (9.5m ,16m).
Optimized central slewing position increases the lifting capacity of the crane over rear.
Large outrigger span improves the working stability of the crane greatly,
Adopt internationally advanced structure analysis and calculation methods to develop the lifting capacity of crane deeply.
Leading boom manufacturing process in trade.

Main Specifications

Item		Unit	Value	Remarks
Working performance	Max. rated lifting capacity	kg	55000
	Max. load moment of basic boom	kN.m	2009
	Max. load moment of main boom(fully extended)	kN.m	1050
	Max. load moment of basic boom	m	12.6
	Max. lifting height of main boom	m	43.6	These parameters do not include deflection of main boom and jib
	Max. lifting height of jib	m	59.5
Working speeds	Max. hoist rope speed(Main winch)	m/min	120
	Max. hoist rope speed(Auxiliary winch)	m/min	120
	Boom demrricking up time	s	50
	Boom demrricking up time	s	95
	Slewing speed	r/min	0-2.2
Driving	Max. driving speed	km/h	76
	Max. gradeability	%	40
	Turning diameter	m	≤24
	Min. ground clearance	mm	260
	Oil consumption per hundred kilometers	L	43
Mass	Deadweight in driving condition	kg	42000
	Complete vehicle kerb mass	kg	41870
	Front axle load	kg	16000
	Rear axle load	kg	26000
Dimension	Overall dimensions(L×W×H)	mm	13700×2800×3650
	Longitudinal distance between outriggers	m	5.92
	Transversal distance between outriggers	m	Fully extended:7.1, Intermediately extended:4.8
	Tail slewing radius	mm	3900
	Main boom length	m	11.4 - 43.0
	Main boom angle	°	-2 - 80
	jib length	m	9.5,16.0
	Offset	°	0,30
