Home > Products > Lifting Machinery > All Terrain Crane 150t ZAT1500 with good price
All Terrain Crane 150t ZAT1500 with good price
USD $10,000 - $150,000
/ Unit
1 Unit(Min.Order)
- 100 Unit / Units per Month
- Shanghai port
- T/T Credit Card
You May Like
- 25 ton telescopic pickup STC250H truck crane for sale
- 50 ton pickup truck lift crane QY50KA truck crane
- China new QY50KA 50 ton hydraulic truck crane price
- mobile pickup 50 ton crane QY50KA truck crane
- China hot sale 55 ton crane SCC550E crawler crane
- mini 55 ton mobile lifting crawler crane SCC550E
Product Details
Brand Name: | SANY | Place of Origin: | Hunan, China | Certification: | ISO |
Warranty: | 1 Year | Application: | Construction | ||
Condition: | New | Span: | 9.0 X 8.5 m | Rated Lifting Moment: | 4704KN.m |
Rated Loading Capacity: | 150ton | Max. Lifting Height: | 87m |
Product Description
All Terrain Crane 150t ZAT1500 with good price
Product Description
Item | Unit | Value | Remarks | |
---|---|---|---|---|
Working performance | Max. rated lifting capacity | kg | 150000 | At 3m radius |
Max. load moment of basic boom | kN.m | 4704 | At 6m radius | |
Max. load moment of max. length boom boom(fully extended) | kN.m | 1505 | At 32m radius | |
Max. load moment of basic boom | m | 13.0 | ||
Max. lifting height of main boom | m | 72 | These parameters do not include deflection of main boom and jib. The value in the brackets is the value with the extension installed. | |
Max. lifting height of jib | m | 87/(95) | ||
Working speeds | Max. hoist rope speed(Main winch) | m/min | 114 | At the 4th layer |
Max. hoist rope speed(Auxiliary winch) | m/min | 74 | At the 3rd layer | |
Boom derricking up time | s | 94 | ||
Boom extendingt time | s | 860 | ||
Max. Slewing speed | r/min | 1.4 | ||
Driving parameters | Max. driving speed | km/h | 75 | |
Max. gradeability | % | 40 | ||
Turning diameter | m | ≤20 | ||
Min. ground clearance | mm | 305 | ||
Limits for exhaust pollutants and smoke | Conform to related standards | |||
Fuel consumption per hundred kilometers | L | 76 | ||
Mass | Deadweight in driving condition | kg | 60000 | |
Complete vehicle kerb mass | kg | 59805 | ||
Load on axles 1,2 and 3 | kg | 12000 | ||
Load on axles 4 and 5 | kg | 12000 | ||
Dimensions | Overall dimensions(L×W×H) | mm | 15390×3000×4000 | |
Outrigger spread(L) | m | 8.43 | ||
Outrigger spread(W) | m | Fully extended:7.8, Intermediately extended:5.3 | ||
Main boom length | m | 13.5 – 72 | ||
Boom angle | ° | -0.5 - 82 | ||
Jib length | m | 11,18.6 | ||
Jib + extension length | m | 26.6 | ||
Offset | ° | 0,30 |
