China Famous Brand S ANY STC200S Truck Mounted Crane for Sale Price

Name: China Famous Brand S ANY STC200S Truck Mounted Crane for Sale Price
Brand: S ANY
Availability: InStock

FOB Price

US$ 50,000 - 60,000 / Unit

1 Unit(Min. Order)

Port Shanghai
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	S ANY	Place of Origin	Hunan, China
Certification	ISO CE
Warranty	1 Year	Application	Construction
Condition	New	Span	5.1*6.0m
Rated Lifting Moment	860kN.m	Rated Loading Capacity	20000kg
Max. Lifting Height	41.5m

Product Description

China famous brand S ANY STC200S truck mounted crane for sale price

Please Contact

Steven Zheng

Newindu E-Commerce (Shanghai) Co.,Ltd.
Add: Suite 1326, Fortune Times Tower, No. 1438 North Shanxi Road, Shanghai, China
Mobile / Whatsapp/ Wechat: +86-13063433538

Email: Steven at
Web:

Product Description

Features -- SANY Truck Crane STC200S

Double-axle drive is used, providing good tafficability and comfortableness under complex road condition with reliable traveling performance.

Engine has the multimode power output function, which reduces power consumption.

The use of tipping over early-warning technology provide

Parameter -- SANY Truck Crane STC200S

Capacity	Max. lifting capacity	20 t
Dimensions	Overall length	12590mm
	Overall width	2500mm
	Overall height	3645mm
	Axles	3
	Axle distance-1,2	4280mm
	Axle distance-2,3	1350mm
Weight	Overall weight	29400kg
	Front axle load	6800kg
	Rear axle load	19600kg
Engine	Model	Imported engine
	Rated power	213kw/2100r/min
	Rated torque	1050N·m/1200~1400r/min
	Emission standard	Euro V
Traveling	Max. traveling speed	80km/h
	Min.turning radius	10m
	Min. ground clearance	220mm
	Approach angle	19°
	Departure angle	13°
	Max. gradeability	38%
	Fuel consumption per 100km	35L
Main Performance	Temperature range	-30~+60
	Min.lifting radius	3m
	Tail swing radius of superstructure	3m
	Boom section	4
	Boom shape	U-shaped
	Max. lifting moment-Base boom	880kN·m
	Max. lifting moment-Full-extend boom	504kN·m
	Max. lifting moment-Full-extend boom+jib	246kN·m
	Length-Base boom	10.55m
	Length-Full-extend boom	33.5m
	Length-Full-extend boom+jib	41.5m
	Outrigger span(Longitudinal/Transversal)	5.1mx6m
Working Speed	Max. single rope lifting speed of main winch(no load)	120m/min
	Max. single rope lifting speed of auxiliary winch(no load)	105m/min
	Full extend/retract time of boom	55/45s
	Full raise/lower time of boom	50/50s
	Swing speed	0~2.2 r/min
Aircondition	HVAC in up cab	Cooling
Aircondition	HVAC in low cab	Cooling and Heating
