90t Truck Crane QY90K in Dubai
US$ 63,000 - 64,000
/ Unit
1 Unit(Min. Order)
- Shanghai Port
- T/T Credit Card
You May Like
Product Details
| Brand Name | NEWINDU | Place of Origin | Jiangsu, China | |
| Certification | ISO CE | |||
| Warranty | 1 Year | Application | Construction | |
| Condition | New | Span | 7.1m | |
| Rated Lifting Moment | 3234kN.M | Rated Loading Capacity | 53ton | |
| Max. Lifting Height | 71m |
Product Description
90t Truck Crane QY90K in Dubai
Main Parameters
| Type | Item | Parameter | |
| Capacity | Max. Lifting Capacity | 90t | |
| Dimension | Overall Length | 14700 mm | |
| Overall Width | 2800 mm | ||
| Overall Height | 3900 mm | ||
| Weight | Overall Weight | 53000 kg | |
| Front Axle Load(axle1,2,3) | 9000/9000/13000kg | ||
| Rear Axle Load(axle 4,5) | 13000/9000 kg | ||
| Engine | Model | - | |
| Rated Power | 174kw/2300rpm | ||
| Rated Torque | 845N.m/1400 rpm | ||
| Traveling | Max.traveling speed | 80km/h | |
| Min. Turning Radiums | 23m | ||
| Min. Ground Clearance | 315mm | ||
| Approach Angle | 20° | ||
| Departure Angle | 16° | ||
| Max. Gradeability | 45% | ||
| Fuel Consumption per 100km | 60L | ||
| Main Perfomance | Base Boom | 12.3m | |
| Fully Extended Boom | 55m | ||
| Fully Extended Boom+jib | 71m | ||
| Longitudinal Outrigger Span | 7.5m | ||
| Lateral Outrigger Span | 7.1m | ||
| Working Speed | Boom Luffing Time | 75s | |
| Boom Full Extension Time | 600s | ||
| Max.Swing Speed | ≥2 r/min | ||
| Max.Speed of Main Winch (single rope)(no load) | ≥ 120 m/min | ||
| Max.Speed of aux. Winch (single rope)(no load) | ≥85 m/min | ||
Product Image
