SIE Super Clear Industrial Video Endoscope
- SHENZHEN
- T/T Credit Card
You May Like
-
JSF08 High Precision Short Fiber Morphology and Mechanical Property Tester
-
HJDL-2 Various Sulphur Determination Device
-
ESH105 Halogen Moisture Detector
-
S400 Near Infrared Agricultural Product Quality Analyzer
-
MDS -7 Automatic Frequency Conversion Controlling Temperature Pressure Microwave Extraction Apparatus
-
SMC 30C-1 Osmotic Pressure Molar Concentration Measuring Instrument
Product Details
| Brand Name | YaTaiGuangDian | Place of Origin | Shaanxi, China | |
| Model Number | SIE |
Product Description
SIE Super clear industrial video endoscope
Brief introduction
The world's leading micro CMOS image sensing system, the physical resolution of 1024*768;
8 inch super clear touch screen and 15000lux brightness optical fiber lighting system;
Even at night, also can make detection in the field of equipment defect lucidity;
front and side double camera, no dead angle detection.
Features
The highlight of the LED packaging technology, the probe illumination of 15000lux - 150 times the illumination of the indoor fluorescent lamp
5 level brightness adjustable
The control structure of the electromagnetic rocker, 360 degrees of the probe is arbitrary bending - excellent flexibility, with a thumb can easily control the probe steering, greatly reducing the fatigue of the long operation of the staff.
Automatic locking, fixed point memory - probe in any bending state, only to maintain 3 seconds, you can automatically lock; lock after the opening point of memory function, and then operate the joystick, the probe will be the angle of the lock for bending
8 inch ultra clear touch industrial display, windows interface, to get started faster, more easily;
Basic menu icons, all functions at a glance
Compact and portable, equipped with portable and shoulder strap design, easy to carry
All metal case, more durable
The insertion tube is made of four layers of tungsten alloy, the wear resistance and corrosion resistance.
The insertion tube is connected to the host by the soft cushion design is not easy to break off, --;
Large capacity 32G TF card storage -- can be extended to 128G
Large capacity battery, which can work continuously for about 5 hours.
Between the main engine and the control rod is connected with the quick intubation, the control rod and the main engine, the maximum separation distance can reach 2 meters, and the field adaptability is stronger.
Host behind the ad hoc structure of the human nature, the use of no need to keep the host in the hands of the host
Fuselage with VGA interface, can be connected to the big screen display, easy to share analysis
Technical parameter
SIESuper clear industrial video endoscope | |
1,Insert tube camera | |
external diameter | 6.4±0.1 mm |
length | ≤3±0.1 meters(can be customized) |
process | Tungsten alloy steel wire braided 4 layer tube |
effective pixels | 1 million pixel |
depth of field | 20mm~70mm |
field angle | 60° |
Waterproof grade | IP67 |
2,endoscope host | |
Standby time | 6h |
LCD | 1024*768 ,8″IPS industrial hd touch LCD screen |
Touch screen function | Each function buttons, menus, Settings, video and take photos |
Signal output | VGAsync output |
storage medium | 32G high speed card |
interface | USB,SD card,DC interface |
white balance | automatic |
file management | Support image/video play, delete, and formatting |
image format | JPG/PNG |
Video format | AVI |
Image/video | Record the date and time |
software upgrading | Upgraded by interface |
3,Endoscopic controller configuration | |
Guide bearing | 360°arbitrary direction |
Guide angle | ≥120° |
direction lock | Rocker automatic locking |
control column | 360°Omnidirectional bending |
orientation | Rocker automatic locking direction function |
Key function | Video, pictures, brightness control |
brilliance control | Five Levels brightness manual adjustment |
maximum brightness | ≥15000Lux |
4,combining form | |
Endoscopic controller | Separate millions of pixels to the controller |
Endoscopic host | Separate megapixels endoscopic host |
5,Working environment | |
Host working temperature | -10℃~40℃ |
Video probe working temperature | -20℃~50℃ |
storage temperature | -10℃~40℃ |
Waterproof | Video probe:IP67 |
