VM3 Vibrating Cup Mill Grinding Machine

Introduction
The Vibrating Cup Mill VM series is primarily used for sample preparation for spectroscopic analysis. The instrument is suitable for rapid and lossless fine grinding of samples to produce samples with analytical grade fineness. The medium-hard, hard, brittle, and fibrous samples can be sampled (ie, dry milled) in a dry state. The compact floor plan not only saves space, but also facilitates placement. Considering the movement of the whole machine, we specially install the casters on the bottom of the vibrating cup mill.
working principle
The vibrating cup mill VM series achieves comminution by pressure, shock and friction. The quick hold device secures the grinding kit to the vibrating chassis. Through the transmission, the vibrating chassis produces a dramatic three-dimensional vibration mode, which causes considerable impact force, friction and rolling pressure between the grinding kits, and concentrates on the sample, so that the sample is powdered in a very short time. .
Applications
Sample properties: medium hard, hard, brittle, fibrous samples
Typical samples: oxide ceramics, glass, cement, lime slag, concrete, soil, paving stones, slag, coal, coke, corundum, ore
advantage
* Very short grinding time
* Speed is 700-1500 rev / min, continuously adjustable
* The final sample size is small (d95 <75 microns)
* Grinding tank fast fastening
* Automatically recognizes agate cans and limits the speed to 700 rpm
* 5 different grinding kits available in different materials
* In the same type of grinder, VM3 has a unique design to help move the grinding cup
* Robust positioning, unique quick fastening design, very safe operation
* Easy to operate control panel
Grinding kit advantages
* The bottom of the grinding kit has a positioning and power-assisted design for easy gripping and fixing
* There is space between the grinding tank and the outer edge of the top cover for easy opening
* With O-shaped outer seal design to protect the seal and extend the service life
* All tanks are made of stainless steel to extend their service life
* The tank is printed with an identification mark (volume, material)
Technical Parameters
Injection size: <15 mm
Sample size: <40 microns
Speed: 700~1500 rpm, adjustable speed
Grinding time: 00:01-99:59 (minutes/second)
Batch processing sample: 1 part
Batch throughput: 20-250 g
Grinding kit capacity: 50 ml, 100 ml, 250 ml
Grinding kit materials: hard steel, tungsten carbide (50 ml, 100 liters, 250 ml), agate (700 rpm), zirconia
Rated power: 1.5 kW
Rated voltage: 220 volts / 50 Hz
Instrument size (horizontal * vertical * height): 800 * 655 * 1255 mm
Package size (horizontal * vertical * height): 1130 * 1030 * 1470 mm
Instrument weight: 277 kg
