EA101 Intelligent Infrared NDIR CO2 Carbon Dioxide Analyzer Meter

Brief introduction

CEA-800A is a flexible configuration of a single gas detector, and can detect the temperature and humidity of the indoor environment. An instrument with 500 groups of data storage, equipped with USB interface, can be connected to the computer, the detection precision is high. Has a very clear color touch screen, sound and light alarm, with a built-in pump, which in very bad work environment can also detect hazardous gases and prompt the operator to prevent. Intelligent infrared carbon dioxide gas detector for the detection and monitoring of health supervision in public places, monitoring station, safety protection, plant, landfill gas etc..

Features

1. Detect infrared carbon dioxide in the air, at the same time can detect the temperature and humidity of the environment.

2. The instruments with data storage, query function, storage of up to 500 groups of data.

3. Bring getter pump can be dozens of meters distance gas suction apparatus are measured.

4. With USB data interface, data can be a PC.

5. With large Numbers, color touch screen character display, instantaneous value, peak value, minimum.

6. The instrument shows a PPM and mg/M after two display data, can automatic conversion.

7. The instrument is according to beer's law and gas selectivity of infrared absorption principle is designed. Using the gas filter correlation (G, F, C) technology and infrared detector.

8. A boot or need to show that the introspection, batteries, sensors, sound and light alarm function.

Technical parameters

Detecting gas, carbon dioxide (CO2) in the air preheating time: 2 min

Principle: no infrared spectroscopic method including the method of national standard

Detection methods: infrared method

Range: 0-5000 parts per million (PPM) or extended to 0 ~ 100%;

Working humidity: 85% RH power consumption: ma 500 or less

Battery life: continuous work about 200 hours

Power supply: 220 vac + 10%; 9 VDC + 10%

Sensor life: 24 months

Response time: 10 seconds or less

Battery: 12 v lithium-ion rechargeable batteries

Warning: sound and light alarm

Dimension: 205 x180x98 mm

Working temperature: 0 to 35 ℃

Repeatability: 1% or less (F.S)

The minimum reading: 10 PPM
