NXS-11B rotary viscometer

Introduction

This instrument is a general coaxial cylinder viscometer. It is suitable for the experimental precision measurement of the absolute viscosity and the rheological properties of non Newtonian fluids for various Newtonian fluids.. Can be used in paint, resin, chemical fiber, mineral oil, lubricating oil, cosmetics, syrup, mud, insulation material... Etc.. The instrument can be placed in the laboratory sampling test, but also can be used to insert a portable measurement in the liquid..

The instrument has the characteristics of small size, light weight, rapid measurement, easy reading, accurate and so on. The speed, rotor and external simple equipment have many kinds of specifications, and can meet the wide range of measurement.. The rotating drum system is made of stainless steel and has a strong corrosion resistance.

Features:

1 quick reading, easy reading, accurate indicator.

2 the speed, the rotor and the outer cylinder have many kinds of specifications.

3 drum system made of stainless steel, with a strong corrosion resistance.

Technical parameters:

1. Themeasuring range (eta) : 2.8 ~ 1.78 x 107 mPa, s

2. Shear stress (tau) : 27.67 ~ 21970 Pa

3. The shear rate (Ds) : 1.23 ~ 996 s - 1

4.Speed: 5.6 ~ 360 r/min

5. Reproducibility:plus or minus 1% (f. S)
