It is high tensile AISI316 stainless steel wire, tolerance(+/-0.01mm), tensile strength is more than 900Mpa (900N).
The holes are square and the wires are very strong (not sliding), screen surface is flattened after we weave the wires to mesh screen.
Characteristic of marine grade security mesh:
Safe: Not easy to cut and break pass AS5039-2008
Private live: No one can peep at room
Beautiful: Gorgeous surface
Durable: More than 10years Warranty pass AS2331.3.1-2001
Mesh Count: as follows
[ Specifications of security mesh]Material |
Mesh Size |
Hole Size |
Sheet Size |
| General tensile 316 Marine grade stainless steel wire | 8mesh×1.2mm | 2.0mm |
Width×Length 750mm×2000mm/2400mm/3000mm3500mm 900mm×2000mm/2400mm/3000mm/3500mm 1000mm×2000mm/2400mm/3000mm/3500mm 1200mm×2000mm/2400mm/3000mm/3500mm 1500mm×2000mm/2400mm/3000mm/3500mm |
| 9mesh×1.0mm | 1.8mm | ||
| 10mesh×0.8mm | 1.8mm | ||
| 10mesh×0.9mm | 1.6mm | ||
| 10mesh×1.0mm | 1.5mm | ||
| 11mesh×0.8mm | 1.5mm | ||
| 11mesh×0.9mm | 1.4mm | ||
| 12mesh×0.7mm | 1.4mm | ||
| 12mesh×0.8mm | 1.3mm | ||
| 12mesh×0.9mm | 1.2mm | ||
| 14mesh×0.5mm | 1.3mm | ||
| 14mesh×0.55mm | 1.2mm | ||
| 14mesh×0.6mm | 1.2mm | ||
| 18mesh×0.32mm | 1.0mm | ||
| High tensile 316 Marine grade stainless steel wire | 8mesh×1.2mm | 2.0mm |
Width×Length 750mm×2000mm/2400mm/3000mm3500mm 900mm×2000mm/2400mm/3000mm/3500mm 1000mm×2000mm/2400mm/3000mm/3500mm 1200mm×2000mm/2400mm/3000mm/3500mm 1500mm×2000mm/2400mm/3000mm/3500mm |
| 8mesh×1.3mm | 1.9mm | ||
| 9mesh×0.9mm | 1.9mm | ||
| 9mesh×1.0mm | 1.8mm | ||
| 10mesh×0.9mm | 1.6mm | ||
| 10mesh×1.0mm | 1.5mm | ||
| 11mesh×0.8mm | 1.5mm | ||
| 11mesh×0.9mm | 1.4mm | ||
|
1.Sheet Size:Can be customized 2.Coating Color:Black/Gray/White 3.Packing:50 pcs per polywood box | |||
[ Features of marine grade security mesh]
Excellent flact surface
High tension,Equal aperture and dia
Corrosion resistance,easy to install
10 years not to corrode,face or bubble
Black color filter 60% of UV rays
[ Maishi marine grade security mesh passes the below tests ]
1) Knife Shear Test(AS5039-2008)
2) Anti-Jemmy Test(AS509-2008)
3) Pull Test(AS5039-2008)
4) Durable more than 10 years(AS2331.31-2001)
5) 3006 Hour Salt Spray Tests, 534 hours UV Test
[ Production Process of marine grade security screens]
You can clearly see our marine grade security mesh quality from following details:
[ Packing and Delivery]
Packing of marine grade security mesh: A piece of waterproof paper between two pieces of mesh,then with wooden cases.
Fumigation certificate supplied.
Delivery time: According to the final order. Usually within 15-20 days.
Payment: T/T, L/C at sight etc.
