Negotiable MOQ: 500 Meters (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
SANMAU
Place of Origin:
China
Model Number:
KW
Contact Supplier Request Quote Chat Now
Dongguan Sanmau Special Weaving Technology Co., Ltd.
Verified Business License
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name SANMAU
Place of Origin China
Model Number KW
Material Other, 100% Kevlar/Para-aramid Fiber
Feature Other, High Tenacity, Flam Resistance
Use Other, Inductrial
Define: Kevlar® & Nomex® Fiber

These two brands are belong to DuPontTM. They are most used ARAMID material, which Kevlar® is para-aramid and always has a natural color of yellow, on the other hand, Nomex® is meta-aramid and has a natural color of white.

Kevlar® has successfully emerged out as one of the ultra high-performance fiber since it’s been first introduced by Stephanie Kwolek on 1971, and was registered by DuPont as a famous para-aramid material commercial brand. This magic fiber has various amazing features: long-term working in high-temperature environment, high tensile load, low elongation.

Advanced Properties of Kevlar® | Para-Aramid fiber

High strength to weight ratio
Low elongation to break
Low thermal shrinkage
Good heat & flame resistance
Self-extinguishing flame retardant properties
Good chemical resistance
Excellent bulletproof/ballistic properties
High cut resistance (not so easy to cut off than normal fibers)
UV resistance good (ONLY on black and other non-natural color fiber)
UV resistance poor (natural, and please notice this is the MAIN WEAKNESS of aramid fiber)

Common Types & Deniers
T-29: Standard Modulus
T-49: High Modulus
AP: 15% higher tenacity than T-29
KM2: Optimized ballistic resistance
Deniers: 200, 380, 400, 750, 800, 1000, 1420, 2160, 2250, 2840, 3000, 7100

Advanced Properties of Nomex® | Meta-Aramid fiber

Lower elongation to break
the 4th level of dye colorfastness, dyeable
Low thermal shrinkage
Excellent heat & flame resistance
Self-extinguishing flame retardant properties
Soft-hand yields good textile properties
High chemical resistance

Common Types & Deniers
T-430: Filament Yarn
Deniers: 200, 1200, 1600, 2400

80mmAramidWebbing
Para-Aramid Yarn Woven Webbing
kevlar-webbing-yarn
80mm in Width, 2mm in Thickness
VariousAramidWebbing
Part of Our Produced Aramid Webbing
ProducingAramidWebbing
Heavy Duty Aramid Webbing in Production
About Kevlar® | Aramid Webbing

Sanmau produced high-performance Webbing is a critical component in protective flame-resistant clothing, harnesses, and helmets required for aerospace, military, first responders, tactical and industrial safety equipment and Personal Protection Equipments (PPE). The protective area includes physical, electrical, heat, chemicals, biohazards, and airborne particulate matters.

Comparision of Materials

For complicated working conditions, ordinary materials are more and more replaced by aramid, UHMWPE, PBO fibers. With these advanced fibers, we managed to develop a series of textile which includes sewing thread, string, rope, straps, webbing, and fabric. Here’s the table of specifications of various materials:

Material Density
(g/cm³)		 Tensile strength
(GPa)		 Specific strength Elastic modulus
(GPa)		 Specific
modulus
Steel re-bar 7.85 0.5 0.0667 210 26.7
A-glass 2.46 2.1 1.35 69 28.0
C-glass 2.46 2.5 1.35 69 28.0
E-glass 2.60 2.5 1.33 76 29.2
S-2 glass 2.49 4.83 1.94 97 39.0
Silicon 2.16 0.206–0.412 0.0954–0.191

Quartz 2.2 0.3438 0.156

Carbon fiber (large) 1.74 3.62 2.08 228 131
Carbon fiber (medium) 1.80 5.10 2.83 241 134
Carbon fiber (small) 1.80 6.21 3.45 297 165
Kevlar K-29 1.44 3.62 2.51 41.4 28.8
Kevlar K-149 1.47 3.48 2.37

Polypropylene 0.91 0.27-0.65 0.297–0.714 38 41.7
Polyacrylonitrile 1.18 0.50-0.91 0.424–0.771 75 63.6
Basalt fiber 2.65 2.9–3.1 1.57–1.81 85–87 32–33
Applications of Kevlar® | Aramid Webbing

Fire Fighting Equipments

Structure Reinfoced

Military Equipments

Terms of Cooperation
Brand Name: SANMAU
Place of Origin: Dongguan, Guangdong, China (Mainland)
Materials for Choice: UHMWPE | Dyneema® | Spectra® Fibers, Para-aramid | Kevlar® Fibers, Meta-aramid | Nomex® Fibers, Polyimide Fibers, PBO Fibers,  Silver|Copper|Steel Conductive Fibers, etc.
Technics: Twisting | Braiding | Weaving | Knitting | Resin Coating | PVC/PP/PE Extrusion Coating for Cords | Cutting & Sewing, etc.
Additional Features: Reflective strips added, Luminous strips added, reinforce the side of webbing by inner steel wire added, tensile strength reinforced, fireproof enhanced, etc.
Color: Fibers’ Natural Color, Several Colored Fibers, Composite Patterns with Different Fibers
The diameter of Ropes: 0.1mm~30mm customized
The width of Webbings: 5mm-310mm customized
The thickness of Webbings: 0.1-5mm customized
Weight of Fabrics: 50gsm~500gsm customized
Manufacturing Capacity: 100,000meters of rope,  50,000meters of webbing, 10,000m2 of fabric, per day, in general
Production Mode: Make-To-Order
MOQ: the value of goods > 1,000USD
Free Sample of Stocking Goods: Yes
Sample Developing: Yes
Payment: T/T, L/C, Western Union, Paypal
Packaging: Rolls in cartons
Delivery Port: Shenzhen


Product Tags: kevlar , webbing , aramid , fireproof , bulletproof , heat resistantce
