Zinc Alloy Anode are cast from high grade zinc alloyed to ensure an even corrosion pattern, reliable electrical efficiency and long working life. The anodes are made to meet ASTM B418 type I standard and U.S. MIL-A-18001K.
zinc anode's protective properties result from a strongly negative reduction potential, which is more negative than the metal it is protecting. Oxidants, which corrode metals, will oxidize the zinc anode rather than the protected metal structure, thus preventing the structure from being corroded.
♦ Chemical compositions of Zinc Anode :
Type |
Al % |
Cd |
Fe % |
Pb % |
Cu % |
Zn. |
I |
0.1-0.5 |
0.02-0.07 |
≤ 0.005 |
≤ 0.006 |
≤ 0.005 |
Balance |
II |
≤ 0.005 |
≤ 0.003 |
≤ 0.0014 |
≤ 0.003 |
≤ 0.002 |
Balance |
♦ Electrochemical properties of Zinc Anode:
Standard |
Open circuit potential —V,Cu/CuSO4 |
Closed circuit potential —V,Cu/CuSO4 |
Actual capacitance (A·h/kg) ≥ |
Current efficiency % |
ASTM B418 I |
≥ 1.05 |
≥ 1 |
780 |
95 |
ASTM B418 II |
≥ 1.1 |
≥ 1.05 |
780 |
90 |
* Special Chemical compositions are available upon request.
We are professional manufacturer and has twenty years experience in anti corrosion industry. Our main products includes
Magnesium casting & Extruded Anode, Magnesium Ribbon anode
Aluminum Anode
Zinc anode, Zinc Ribbon Anode,
High Silicon Cast-Iron Anode
Epoxy Coated Steel Reinforcing Bar
Ant-corrosion Tapes
