| Principal dimensions | Load ratings | Speed limits | Weight | Dimensions | Calculation factors | ||||||||
| Part number | Bore | Outer | Width | Dynamic | Static | Grease | Oil | ||||||
| d | D | B | C | Co | rpm | Kg | r1/r2 | e | Y1 | Y2 | Y0 | ||
| mm | kN | 1 min−1 | mm | mm | |||||||||
| 1218 | 90 | 160 | 30 | 57,0 | 23,10 | 3800 | 4500 | 2,500 | 2,0 | 0,17 | 3,7 | 5,7 | 3,9 |
| 1318 | 90 | 190 | 43 | 117,0 | 44,50 | 3000 | 3600 | 5,800 | 3,0 | 0,22 | 2,9 | 4,5 | 3,0 |
| 2218 | 90 | 160 | 40 | 70,2 | 27,20 | 3600 | 4300 | 3,400 | 2,0 | 0,27 | 2,3 | 3,6 | 2,5 |
| 2318 | 90 | 190 | 64 | 153,0 | 57,70 | 2800 | 3400 | 8,450 | 3,0 | 0,38 | 1,7 | 2,6 | 1,7 |
| 1219 | 95 | 170 | 32 | 63,7 | 24,30 | 3400 | 4000 | 3,100 | 2,1 | 0,17 | 3,7 | 5,7 | 3,9 |
| 1319 | 95 | 200 | 45 | 133,0 | 50,80 | 2800 | 3400 | 6,700 | 3,0 | 0,23 | 2,8 | 4,2 | 2,9 |
Self Aligning Ball Bearings have two rows of balls, located on the inner ring
and a spherical outer track. This design permits misalignment of the inner and
outer races caused, for example, by shaft deflection or variation in housing
alignment. These bearings are also manufactured with tapered bore for use
with adapter sleeves. Sealed version available.
Dimensions in accordance with ISO 15:2011
