Requirements for the manufacture of double-layer conductive assembly bags:
Conductive pack bag, also known as TYPE C pack bag, ton bag. A double-layer conductive pack is made of conductive fabric or of fabric interwoven with conductive yarns or bundles. The woven yarn or strand of the conductive cloth must: form a reliable interwoven grid with a large non-conductive area of 25 cm2(50mm); Or the distance between interweaves is less than 20mm(yarn or strand interweaves at least twice).
The grounding impedance of conductive cloth and conductive yarns or bundles of conductive aggregate bags(TYPE C) is less than 108 Ω. In addition, all the following requirements must be met: If the FIBC has an insulating coating inside, the thickness of the coating must be less than 2mm, and the breakdown voltage of the conductive fabric and yarn or strand must be less than 4kV.
The inner and outer layers of the double-layer conductive assembly bag(TYPE C) are all stitched by conductive silk woven into a conductive cloth. Its moisture-proof, leakproof, durability and other practicalities far exceed the single-layer conductive pack bag. The safety factor of the double-layer conductive assembly bag is 6:1, which can be reused.
Conductive pack fit environment
Loose material
environment
Dust MIE
Non-combustible environment
Dust explosion environment
Gas, Steam explosion environment(Class 11A or 11B)
MIE & GT; 1000 mJ
A, B, C, D
B, C, D,
C, D
1000 mJ & GT; MIE & GT; 3mJ
B, C, D
B, C, D
C, D
3 mJ & GT; MIE.
C, D
C, D
C, D
