Product Description
Tisco Hadfield manganese X120 mn12 steel sheet plate 1.3401 A128
- Plates 3mm to 5mm thick, 900mm to 1100mm wide and up to 2200mm long.
- Plates 6mm to 40mm thick, 1500"mm to 1900mm wide and up to 10000mm long.
The characteristics of X120MN12 :
- high abrasive resistance,and impact toughness
- Work hardening steel - the more impact and abrasion it gets the harder the surface becomes.
- Steel stays ductile underneath - as the surface wears - only outer layer gets hard.
- With continued impact the manganese steel can harden to HB500 above.
- When rolled - never brittle.
- Work hardened surface is almost friction-less.
- Non-Magnetic
- Quenched, annealed and austenitic
- Can be cut by plasma / laser / water jet / oxy-acetylene
- Made to ASTM A128 standards, EN X120Mn12, DIN 1.3401,JIS SCMnH11, and China National Standard GB Mn13
Chemical composition:
Grade | Chemical composition(%) | |||||
X120Mn12 | C | Si | Mn | P | S | Cr |
0.9-1.3 | 0.3-0.5 | 12-13 | Max0.1 | Max0.04 | Max1.5 | |
Mechanical Properties :
Tensile Strength | Elongation | 20°C Impact Resistance | Initial Hardness(HB) | Hardness after Hardened(HB) | 180°old Bending Test |
≥900MPa | ≥40% | ak≥50(J) | 190-250 | ≥300 | Qualified |
Mechanical properties
