Hard Chrome Piston Rod Chromium Rods Hard Chrome Shaft

Hard Chrome Piston Rod Chromium Rods  Hard Chrome Shaft

Xinpeng Have passed ISo9001 verified from 2008; each tube of ours is strictly in quality control that can assure the product quality of Xinpeng. Mainly produce precision tube as cold drawn/rolled tube honed and SRB tube, mainly used in Hydraulic cylinder and mechanical using.

1.Grade:20#(ck20,aisi1020),45#(ck45,aisi1045),st52(16Mn,Q345D),25Mn(STKM13CSt52 Hydraulic Cylinder using Cold drawn Seamless pipe-T),27SiMn

2.ID:30-250mm

3.ID tolerance:H8,H9

4.Surface roughness:Ra 0.02— 0.4μm

5. Final supply condition:cold drawn and stress-relieved(BK+S)

6. Machining allowance:0.5-1.5mm

7.Wall thickness:10%×ID

1.Hydraulic cylinder tube

The hydraulic cylinder tube is the main part of the hydraulic cylinder.The inner
hole of the hydraulic cylinder tube usually precision processed by boring,reaming,rolling

or honing.By these process can ensure the piston,sealing elements and the support
elements move smoothly,then ensure the sealing effect and reduce the abrasion.The
hydraulic cylinder tube will bear big pressure,so need high strength and stiffness.

2.Hydraulic Tube Material
JIS STKM13C, DIN ST52, SAE1020 or Mechanical Construction Use Carbon Steel Pipes, Other Specifications Can be made Customer Request based on.

Hydraulic pneumatic liner actuator standard/size/precise

Mechanics performance

Dimension tolerance

Material range of YANTAI XINPENG

Our Company

We are professional supplier of  steel tubes, cold drawn steel tube, cold rolled steel tube,

cold drawn honed steel tube, cold drawn rolled honed tube, honed tube, SRB tube, hydraulic

cylinder pipe and so on.

O

Our Workshop

Our Company is equipped with JLB250T hydraulic cold drawn machine set,LD120 precision cold rolled machine set, multiple precision straightening machine,box heat treat furnaces(8000-10000mm), advanced CNC skived and roller burnished machine SRB-6000mm, several powerful honed machine, combined cold drawn, cold rolling, heat treatment, and SRB process to produce the best quality products.

Product Process

Our Products

Honing tube and rolling tube inside and outside wall oxide layer, to withstand high pressure without leakage, high-precision, high-quality finish, cold deformation, flaring, flattening without cracks a bit, so mainly used to produce pneumatic or hydraulic components products, such as cylinder or cylinders, which can be seamless. Chemical composition of two kinds of materials are C, Si, Mn , S, P, Cr. Relatively speaking rolling tube better than honing tube good.

Application

Hydraulic cylinder tube st52 din2391 widely used in hydraulic system with precision steel tube, injection molding machine with precision steel tube, hydraulic press with precision steel tube, shipbuilding with steel tube, EVA foaming, hydraulic machinery, hydraulic cutting machine, shoe making machinery, hydraulic equipment, high pressure tubing, hydraulic tubing, card sets of joints, pipe joints, rubber machinery, forging machinery, casting machinery, engineering machinery, automotive high pressure steel pipe concrete pump, sanitation vehicle, automobile industry, shipbuilding industry, metal processing, military industry, diesel engine, the internal combustion engine, air compressor, construction machinery, forestrymachinery, etc.

Package

The packaging process and other terms

Transportation: by sea
20' FCL (means the length than 5,800mm)
40' FCL (means the length than 11,800mm)
Bulk cargo (means the quantity is more than 200MT)
With regards to other length or quantity, it should be taken by clients themselves
Delivery time: 10-30days to the dispatch port after receipt of T/T or L/C at sight
Optional: wooden box; caps; vanished coating. Clients should pay for this fee
Payment: T/T or L/C at sight, T/T 100% in advance (the order less than 30MT)
Price item: FOB, CFR, CNF, C&F, CIF
Origin: China

Our Service

TEL:+86-535-6835398

our testing
