Rexroth CGH1 series of CGH1MF3,CGH1MT4,CGH1MS2 heavy load double rod hydraulic cylinder,oil cylinder
- 5000 Unit / Units per Month
- Ningbo/Shanghai
- T/T Credit Card
-
Rexroth CG210B,CG210G,CG210C,CG210H,CG210D,CG210K,CG210R,CG210E,CG210S,CG210F,CG210L,CG210M,CG210N,CG210T, hydraulic cylinder
-
Rexroth CG70C,CG70H,CG70R,CG70E,CG70F,CG70L,CG70M,CG70N,CG70P light duty hydraulic cylinder
-
Rexroth CDT3ME5,CDT3MP5,CDT3MT4,CDT3MT2,CDT3MX2,CDT3MX5,CDT3MP3,CDT3ME6,CDT3MS2,CDT3MT1,CDT3MX1,CDT3MX3,hydraulic cylinder
-
Rexroth CDM1 series of CDM1M00,CDM1MP3,CDM1MP5,CDM1MF1,CDM1MF2,CDM1MF3,CDM1MF4,CDM1MT4, heavy load hydraulic cylinder
-
Rexroth CDH3 series of CDH3MP3,CDH3MP5,CDH3MF3,CDH3MF4,CDH3MT4,CDH3MS2, heavy load hydraulic cylinder,oil cylinder
-
Rexroth CDL2 series of CDL2MP5,CDL2MT4,CDL2MF3,CDL2M00, heavy load hydraulic cylinder,oil cylinder
Product Details
| Brand Name: | Associated | Place of Origin: | Zhejiang, China | Model Number: | CGH1MF3,CGH1MT4,CGH1MS2 |
Packaging Details
Standard export carton/plywood case
Product Description
Rexroth CGH1 series of CGH1MF3,CGH1MT4,CGH1MS2 heavy load hydraulic cylinder,oil cylinder
1. Double rod type, and double-acting piston
2. Tie rod design
3. Component series 3X
4. Rated pressure 250bar
5. Piston dia. Ø 40 …320 mm
6. Stroke length up to 6000 mm
7. Completely interchangeable with original
8. Very competitive price
9. 1 year of warranty
Technical Specifications:
