8Ton Flake Ice Maker
The marine ice machine is a kind of sea water ice machine installed on the fishing boat.
8T/Day Marine Flake Ice Machine Application
The flakes have no sharp edges and corners and will not stab frozen objects. It can enter the gap between the objects to be cooled, reduce heat exchange, maintain the temperature of ice, and have a good moisturizing effect.
Flake Ice Feature
The flakes are flakes, dry and loose white ice, ranging in thickness from 1.0 mm to 2.5 mm, irregular in shape and about 12 to 45 mm in diameter.
High Reliability and Low Breakdown Rate
High Efficiency and Energy Saving
Simple Maintenance and Convenient Moving8Ton/Day Industrial Flake Ice machine specificatio
Item Name |
Sea Water Ice Machine |
Fresh Water Ice Machine |
Model |
YTC-8TS |
YTC-8TF |
Compressor power |
50HP |
40HP |
Ice Evaporator |
Stainless Steel 304 |
Carbon Steel |
Daily Output |
8000kg/24H |
8000kg/24H |
Ref.Capacity(Kcal) |
51600 |
41280 |
Temp.Evaporator(℃) |
-18(℃) |
-22(℃) |
Temp.Condenser(℃) |
40(℃) |
40(℃) |
Total Power (kw) |
41.84 |
35.24 |
Cooling Mode |
Air Cooled |
Air Cooled |
Power Supply |
380V/3PH/50Hz |
380V/3PH/50Hz |
Refrigerant |
R404 |
R404 |
Unit Weight |
1180 |
1020 |
Unit Size |
2300x 1900x 1720mm |
2300x 1900x 1720mm |
Ice Storage Size |
2300x2300x2000 |
2300x2300x2000 |
