61813 16013 6013 6013 ZZ 6013 2RS 6213 6213 ZZ 6213 2RS 6313 6313 ZZ 6313 2RS 6413 Ball Bearing

61813 16013 6013 6013 ZZ 6013 2RS 6213 6213 ZZ 6213 2RS 6313 6313 ZZ 6313 2RS 6413 Ball Bearing thumbnail-1
61813 16013 6013 6013 ZZ 6013 2RS 6213 6213 ZZ 6213 2RS 6313 6313 ZZ 6313 2RS 6413 Ball Bearing thumbnail-2
61813 16013 6013 6013 ZZ 6013 2RS 6213 6213 ZZ 6213 2RS 6313 6313 ZZ 6313 2RS 6413 Ball Bearing thumbnail-3
61813 16013 6013 6013 ZZ 6013 2RS 6213 6213 ZZ 6213 2RS 6313 6313 ZZ 6313 2RS 6413 Ball Bearing thumbnail-4
61813 16013 6013 6013 ZZ 6013 2RS 6213 6213 ZZ 6213 2RS 6313 6313 ZZ 6313 2RS 6413 Ball Bearing thumbnail-5
61813 16013 6013 6013 ZZ 6013 2RS 6213 6213 ZZ 6213 2RS 6313 6313 ZZ 6313 2RS 6413 Ball Bearing photo-1
61813 16013 6013 6013 ZZ 6013 2RS 6213 6213 ZZ 6213 2RS 6313 6313 ZZ 6313 2RS 6413 Ball Bearing photo-2
61813 16013 6013 6013 ZZ 6013 2RS 6213 6213 ZZ 6213 2RS 6313 6313 ZZ 6313 2RS 6413 Ball Bearing photo-3
61813 16013 6013 6013 ZZ 6013 2RS 6213 6213 ZZ 6213 2RS 6313 6313 ZZ 6313 2RS 6413 Ball Bearing photo-4
61813 16013 6013 6013 ZZ 6013 2RS 6213 6213 ZZ 6213 2RS 6313 6313 ZZ 6313 2RS 6413 Ball Bearing photo-5
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
HPC or Natural or OEM
Place of Origin:
China
Model Number:
61813 16013 6013 6013 ZZ 6013 2RS 6213 6213 ZZ 6213 2RS 6313 6313 ZZ 6313 2RS 6413
Contact Supplier Request Quote Chat Now
Integration Trading (Xiamen) Co.,Ltd
Verified Business License
Payment & Shipping
Payment Methods:
Port of Shipment:
Xiamen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name HPC or Natural or OEM
Place of Origin China
Model Number 61813 16013 6013 6013 ZZ 6013 2RS 6213 6213 ZZ 6213 2RS 6313 6313 ZZ 6313 2RS 6413
Number of Row Single Row
Seals Type Open, Seals, Shields
Precision Rating P6/Z3V3
Outside Diameter 85, 160
Bore Size 65,

Principal dimensions Load ratings Speed limits Weight Radius
Part   number Bore Outer Width Dynamic Static Grease Oil

d D B C Co rpm Kg rs min

mm kN 1 min−1 mm
61813 65 85 10 12,2 12 7000 8500 0,13 0,60
16013 65 100 11 22,9 19,6 6300 7500 0,3 0,60
6013 65 100 18 31,9 25,2 6300 7500 0,44 1,10
6013 ZZ 65 100 18 31,9 25,2 6300
0,44 1,10
6013 2RS 65 100 18 31,9 25,2 4000
0,44 1,10
6213 65 120 23 57,2 40 5300 6300 1 1,50
6213 ZZ 65 120 23 57,2 40 5300
1 1,50
6213 2RS 65 120 23 57,2 40 3600
1 1,50
6313 65 140 33 92,7 59,7 4800 5600 2,1 2,10
6313 ZZ 65 140 33 92,7 59,7 4800
2,1 2,10
6313 2RS 65 140 33 92,7 59,7 3000
2,1 2,10
6413 65 160 37 118 79 4000 4800 3,3 2,10



The single row deep groove ball bearing is the most popular type of rolling bearing. Because the inner and outer raceway radii are only slightly larger than the ball diameter,

it has considerable axial load carrying capacity in either direction, as well as radial loading. It is suitable for high speeds and can be supplied with shields or seals - for example, suffix ZZ is added for shielded type, and suffix 2RS is added for sealed type.



The shielded types have a running clearance between the inner race and the metal shield; whereas, the sealed types (with seals made from synthetic rubber) make contact with the inner race. Both shielded and sealed bearings are supplied with the correct amount of lithium base grease, which has an operating temperature of -30 to +120°C

(-22°F to +248°F).



Cages are normally two pieced pressed steel. For higher speeds, machined brass cages and reinforced plastics are used. Plastic cages are limited on operating temperature to about 120°C (248°F) maximum.



Deep Groove Ball Bearing can also be supplied with snap ring and groove, which provide a simple and space-saving means of locating the bearing in the housing. Bearings with this feature have the suffix NR added to the designation.



Dimensions in accordance with ISO 15:2011
