Small Scale Vegetable Oil Refining Machine

vegetable cooking oil refining machine process:

♥ Acid reaction process
Oil temperature can be adjusted by screw plate heat exchanger. When the temperature is heated to about 80℃, mixing about 85% food grade phosphoric acid into acid reaction tank for reacting.

 Neutralization process
In neutralization section, adding alkali liquor with appropriate concentration into the degummed oil which have proper temperature, then degummed oil enters into the centrifugal mixer for mixing.

 Washing process
Neutralized oil come from neutralization separator, still contains about 500 ppm soap. During the washing, hot water will absorb the soap and other impurities in oil, then soap and impurities are separated in washing separator.

Vacuum drying section
The neutralization and washing oil come from the washing separator still contains some water which is adverse to the oil stability.

Bleaching process
The main purpose of this process is to remove the pigments in crude oil and the residual soap in the neutralization oil.

Filteration

Miscella mixed by oil and clay from bleaching tower is pumped into decolorizing filter, then enters into fine filter, in which clay and fixed impurities are blocked.

Deodorization process
Deodorization process aims to remove the FFA and low molecular compounds in bleached oil. Entering into the deodorization process, the flow of bleached oil is controlled by a flow controller, and the oil is heated to250-260℃ through a series of heat exchanger, then the temperature can reach to the condition of deodorizing.

 Dewaxing process

Bleached sunflowerseed oil enter into crystallizing tank through heat exchanger and begin the cooling crystallization proces,this process is controlled by the computer through the parameters preestablished,the computer controls temperature of circulating water in the frozen coil to comand cooling speed of the oil,thereby receive the best crystal result.

Gongyi Dachang company is specialized in manufacturing various of oil press machine(mini oil press machine, screw oil press machine, and hydraulic oil press machine,etc.), food machinery(breakfast maker, meat grinder,slicer,etc. ), baking machinery(dough roller, dough mixer, oven, etc.)and packing machinery in China. Our company is located in Zhengzhou City, Henan Province. The technology, trade and service is the core of our company, and we are committed to global customers with high standards of producing manufactures, and a full range of technical services and efficient solution.
