Oil Making Machinery With Best Performance

Oil Making Machinery With Best Performance photo-1
Oil Making Machinery With Best Performance photo-2
Oil Making Machinery With Best Performance photo-3
Oil Making Machinery With Best Performance photo-4
Oil Making Machinery With Best Performance photo-5
Oil Making Machinery With Best Performance photo-6
Oil Making Machinery With Best Performance photo-7
US$ 4,365 - 7,099 MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
Lewin
Place of Origin:
Henan, China
Type:
Cold & Hot Pressing Machine
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai Tianjin Guangzhou
Delivery Detail:
Delivery time depends on order quantity.
Brand Name Lewin
Place of Origin Henan, China
Type Cold & Hot Pressing Machine
Certification ISO CE
Weight 1750kg
Dimension(L*W*H) 860*1080*1650(mm)
Voltage 380V
Condition New
Automatic Grade Automatic
Detailed Images

The following is the specific introduction:
Main engine includes base, upright, top plate, oil drip pan, nut and etc which is one of the main parts. When the oil material is put into the assembly of the press boring, then it being driven up by the oil cylinder piston, oil will be outflow from the gap of press boring, and then pass the oil drip pan to the drum for oil storage.

Product Description

Advantages:

The 6YY series automatic hydraulic oil extraction machine has many advantages: easy to operate, high oil press rate, rare to replace wearing parts. This oil press is the most advanced equipment which can replace of the manual operation of the sesame oil.

This automatic oil making machine can be used for process many kinds of raw material: sesame, walnut kernel, peanut, pine seed (better to get rid of the shell), almond, spricot kernel, perilla, cocoa bean, linseed, avocado and other oil crops.

If you want to process other raw materials,please tell us to ensure.

Main technical parameter

Model
6YY-4KG
6YY-8KG
6YY-9KG
6YY-11KG
6YY-13KG
6YY-16KG
6YY-
20KG
6YY-
23KG
Capacity
(kg/batch)

4

8.5

9.5

11

13.5

16

20

        23
Working pressure
60Mpa
60Mpa
60Mpa
60Mpa
60Mpa
60Mpa
60Mpa
60Mpa
Weight (kg)
550
920
970
1060
1230
1600
1750
2300
Voltage
380V
380V
380V
380V
380V
380V
380V
380V
Power
(3 phases)
1.1 kw
1.1 kw
1.1 kw
1.1 kw
2.2 kw
2.2 kw
2.2 kw
3.0 kw
Power
( Single)
2.2 kw
2.2 kw
2.2 kw
2.2 kw
4 kw
4.8 kw
4.8 kw
5.0 kw
Dimension(mm)
560*780*1200
680*900*1430
680*900*1530
700*960*1560
740*1000*1600
860*1060*1660
860*1080*1650
960*1160*1760

Main Features
1. The pressure of our machine is higher than others, provide higher oil yield.
2. Internal temperature control parts to solve the problem of low oil yield in winter.

3. The capacity is the quantity of raw material that machine could process in one time.

Packing & Delivery

We have professional transportation team to ensure the safety of your goods

Instructions

We have video or paper manuals to solve problems in operating the machine.

Our Service

After-service:
1). The equipment guarantee period is one year, During guarantee period, the seller will provide maintenance free service.(Except the breakdown and destroy caused by person and force majeure)
2). After receiving the inquiry for repairing the engineer of sell party will solve by phone and email, if necessary the engineer will go to solve the problem on the spot, the buyer should pay daily salary $100, also pay technical visa cost, round trip tickets, rooms and meals.
3). During the quality guarantee period, if it is the quality problem (except easily damaged parts), the cost for maintenance and replace will be borne by sellers.
