Fixed knot fence
--Proven by science to be the toughest fence on the market.
Description
Fixed Knot Fence, also called fixed knot deer fence, deer fence, Field fence, It has excellent strength, flexibility and ease of installation. It has many sizes and spacings suitable for cattle, deer, goats, pigs, horses, bison, elk, sheep and dogs, and can even be used for safety applications.
1.Materials: High-strength galvanized iron wire; High-strength zinc plated steel
2.Surface treatment:
Class A: Electro galvanized fixed knot joint fencing(zinc coated:15g/m²)
Class B: Hot dipped galvanized fixed knot joint fencing(zinc coated:30-50g/m²)
Class C: Heavy hot dipped galvanized fixed knot joint fencing(zinc coated:220-280g/m²)
3.Technical parameters:
Wire diameter and tensile strength:
horizontal wires: diameter 2.5 mm, tensile strength 1100-1300N/mm²
vertical wires: diameter 2.5 mm, tensile strength 600-850N/mm²
knot wires: diameter 2.2 mm, tensile strength 400-525N/mm²
product detail
Specification
FENCE DESIGN |
LINE WIRES |
FENCE HEIGHT |
WIRE SPACING |
ROLL WEIGHT |
COMMON USES |
735-6-330’ |
7 |
35″ |
6″ |
141 lbs |
Hog |
842-6-330′ |
8 |
42″ |
6″ |
157 lbs |
Cattle, Hog |
842-12-330′ |
8 |
42″ |
12″ |
110 lbs |
Cattle, Goat, Sheep |
842-12-660′ |
8 |
42″ |
12″ |
220 lbs |
Cattle, Goat, Sheep |
949-6-330’ |
9 |
49″ |
6″ |
182 lbs |
Cattle, Hog |
949-12-660’ |
9 |
49″ |
12″ |
257 lbs |
Cattle, Goat, Sheep |
1348-6-330’ |
13 |
48″ |
6″ |
234 lbs |
Cattle, Hog |
1348-12-330’ |
13 |
48″ |
12″ |
168 lbs |
Cattle, Goat, Hog, Sheep |
1348-12-660’ |
13 |
48″ |
12″ |
336 lbs |
Cattle, Goat, Hog, Sheep |
1561-3-200′ |
15 |
61″ |
3″ |
280 lbs |
Goat, Hog, Horse, Sheep |
1348-3-200′ |
13 |
48″ |
3″ |
233 lbs |
Goat, Hog, Horse, Sheep |
1561-6-330′ |
15 |
61″ |
6″ |
279 lbs |
Cattle, Hog |
2096-6-330’ |
20 |
96″ |
6″ |
396 lbs |
Deer |
2096-12-330’ |
20 |
96″ |
12″ |
282 lbs |
Deer |
2096-3-165′ |
20 |
96″ |
3″ |
340 lbs |
Cattle, Deer, Hog |
For example, 735-6-330' has 7 line wires, is 35 inches tall, has 6 inch spacing between the vertical stay wires, and is 330 feet long.
Main Technologies
1.High tensile wire
Low carbon wire |
1. Carbon content:approximately 0.06-0.08%. 2. easy to work with and somewhat forgiving. 3. it will sag or stretch over time. |
High tensile wire |
1. carbon content: approximately 0.28%. 2. The increased carbon content significantly increases the wire's strength and reduces elongation. |
The 50-Year Fence saves you money on labor and materials with increased post spacing and less maintenance over the years.
2.Galvanized wire coating
The class 40 zinc-aluminum hybrid coating When building with The 50-Year Fence, you can guarantee unmatched performance by a product that is scientifically proven by an independent research study to last twice as long as Class 3 fence.
3.Fixed knot
Traditional field fence--Because of its wrapped design, the knot on a hinge-joint fence can slide.
The fixed knot--A fixed knot fence will not tear apart under heavy pressure unless the wire itself breaks.
Our company
Application
FAQ
1.Are you a manufacturer?
YES,we are the ISO and CE certificated manufacturer and our factory founded in this industry since 2001
2.Can we visit your factory?
yes,welcome to our factory.
3.How about the deliver time if we order from you?
Generally,it will take about within 30 days after received your advanced payment.It also decided by your total quality.
4.What are the payment terms?
We can accept L/C,T/T,cash,west union,money gram
5.Is it free to provide samples?
Yes,the sample is free,but shipping costs require customers to take care of themselves.
