Nail head speed |
800Nail / min |
The minimum thickness of the board |
4mm |
The maximum thickness of the board |
12mm |
U nail internal width |
12mm |
Flat wire specifications |
17#(2.0x0.75) |
Nail box inclination |
45 |
The minimum distance of nailing |
30mm |
The motor power |
8.6kw |
| The minimum stack width | 300mm |
The maximum stack width |
1600mm |
The minimum stack length |
250mm |
The maximum stack length |
1700mm |
Speed |
120m/min |
The machine finally automatic counting stacking quantitative output
Feed have side flapping device enables the sending paper neatly smooth;The paper feeding motor adopts the servo motor to control, to ensure stable and accurate nail pitch;This machine is designed with box shaping functions, ensure the scissors will not appear in the stitching; the difference is no more than +/- 1mm
completed at a time;The machine can stitch three layer, five layer carton (seven layer need to be declared in advance in order);The machine for bundling part is optional.If deflection during normal operation, the machine will stop automatically.The machine is with three function; stick, stitch, and sticking stitch.
