1 ton animal poultry feed mixer used in small feed mill
Mixing process – Feed Mixer
Efficient mixing is the key to good feed production. The feed will not be the balanced formulation, so it should be well mixed before pelletizing process.horizontal feed mixer is a mechanical means of achieving this. It consists of a series of paddles or metal ribbon blades mounted on a horizontal rotor within a semi-circular trough.The blades move the material from one end of the mixer to the other, tumbling it as it goes. It can mix wet ingredients or mixtures of wet and dry materials, as well as mixing dry ingredients.
SLHY Series Single Shaft Double Belt Mixer:
| Model | SLHYa0.5 | SLHYa1.0 | SLHYa2.0 | SLHYa4.0 |
| Power(kw) | 4 | 7.5 | 15 | 30 |
| Capacity(kg/p) | 250 | 500 | 1000 | 2000 |
1. Adjustable paddle structure.
2. Reliable spray system.
3. Mixing uniformity: ≤7,Mixing time:2-4 minutes.
4. Feed inlet on one side with decompression holes on both sides.
5. The gap between the paddle and the machine slot is adjustable
6. Many liquids--like water, oil, etc,--can be easily added in.
SHW Series Single Shaft Double Belt Mixer:
| Model | SHW0.5 | SHW1.0 | SHW2.0 | SHW5.0 |
| Powe(KW) | 4 | 7.5 | 15 | 30 |
| Capacity(kg/p) | 250 | 500 | 1000 | 2500 |
1. Mixing uniformity≤7,Mixing time:2-3 minutes
2. Widely used in small and medium scale feed plant in the animal and breeding industry
3. Original and patented product.
4. Body section is round to prevent un-mixable angles.
5. No blockage inside;feed inlet on one end for feeding, while packing on the other.
SLHSJ Double Paddle Mixer:
| Model | SLHSJ0.3 | SLHSJ 0.5 | SLHSJ 1.0 | SLHSJ 2.0 | SLHSJ 3.0 | SLHSJ4.0 |
| Power(KW) | 3 | 5.5 | 11 | 18.5 | 22 | 30 |
| Capacity(kg/p) | 150 | 250 | 500 | 1000 | 1500 | 2000 |
1. Mixing in gravity--free state won’t cause segregation.Multiform liquids can be added in.
2. Conveyed by three chains running at a low speed for increased stability.
3. Short mixing period(40-120 sec/batch), mixes evenly at a high rate of consistency (CV=5%,min 2%).
4. Two door structure;discharges rapidly, with no leakage, and little residual.
5. Variable system for adding liquids, and it can be matched with compressed air jetting system.
6. Widely used at premixing compounds,and in the poultry, aquatic feed,chemical, and pharmaceutical industries.
product features:
1.Small feed mixer for sale is widely used in mixing the powder, granule ect ,various liquid can be added. Now it is widely used in animal feed industry, fertilizer industry, aquatic product breeding,chemical industry, aquatic product breeding, medicine and so on.
2.Small feed mixer for sale has two feeding door on top, one is used to add main materials , the other is used to add additive. the output door is manual to discharge. Also it contains liquid pump, which can addliquid , when liquid spray to mixer ,will become steam, making high mixing efficiency.
3.Mixing time is short (3-6minutes/batch). Adding input and output time, the mixing time is about 15-20minutes per batch(full load working), it can mix 3-4 times per hour. The degree of homogeneity is high(cv is smaller than 5%)
Packaging
Packaging:all machines covered by plastic film firstly and then packed in wooden case to best protect the machine during long time transportation.
shipping
Shipping: All machines will be sent by sea, if you need other kind of transportation, please inform us in advance. And all machines would be shipped in 7 days after the receipt of payment. Before and after shipping, we will take photos of machines and send photos to client.
Our service
1. One year quality warranty for the machine and spare parts
2. Overseas engineers service for installation
3. Whole-life after-sales service and free consultation
4. Customized requirements available
5. Technician guide at the site.
6. 24Hr online service
1.About us
Henan Institute Of Grain Machinery Manufacturing Co., Ltd. is established driven by the academy of Henan University of Technology. As a large joint-stock enterprise integrating technology, manufacture and sales, our company is specializing in the production of grain and oil machinery, agricultural and sideline machinery. Cooperating with Henan Mechanical Design and Research Institute and Henna University of Technology (Former Zhengzhou Grain College), Henan Institute Of Grain Machinery Manufacturing Co., Ltd. has carried out the research and application of oil machinery, food machinery, grain machinery, construction machinery, and feed machinery, etc.
we provide a turnkey project of our machinery,including special design,installation, commissioning and training workers.
2.Why choose us
---Advanced equipments,good quality
---Professional skills,all-related services
---High quality and efficiency technology
---Complete production line,quick delivery
---The biggest grain and oil machine manufacturer and exporter in China
---Exporting to more than 30 countries and regions
FAQ
1.Q :Are you the factory?
A:Yes, We are a professional manufacturer for several years.
2.Q: Where is your factory located?
A:Our factory is located in Jiaozuo, Henan Province.
3.Q:How about the INSTALLATION?
A:Engineers available to service machinery overseas,including installation,commission and training,etc.
4.Q:Can your company accept the customized product?
A:Yes,OEM &ODM service is available.We can make the products according to your size,design,color, It will be better if you can send us the product pictures for our reference.
5.Q: How does your factory do regarding quality control?
A: Quality is priority. We always attach great importance to quality control from the very beginning to the end of the production. Every product will be fully assembled and carefully tested before it's packed for shipment.
Any questions, please don't hesitate to contact us!
