Chemical pelletizer machine , Wax paraffin pellet making machinery price

Name: Chemical pelletizer machine , Wax paraffin pellet making machinery price
Brand: YIZE
Availability: InStock

FOB Price

US$ 9,000 - 30,000 / Set

1 Set(Min. Order)

Port Qingdao port or as your request country other port
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	YIZE	Place of Origin	Henan, China
Certification	ISO
Weight	1.2T	Dimension(LWH)	Customized
Condition	New	Product Type	Fertilizer
Voltage	220V/380V	Power(W)	2.2kw

Product Description

Chemical pelletizer machine , Wax paraffin pellet making machinery price

Product Description

Working principle of Paraffin Wax Pellet Making Machine paraffin wax granulation machine

Rotary belt condensation granulator is using low melting point characteristic of the material (50 ℃ to 300 ℃)
Molten material through the special distributing device . Then distributing it on moving steel belt . Use the cooling device which at the bottom of steel belt . Then make the material condensation , solidification . granulation

Technical parameters

Model	YZZL-40	YZZL-60	YZZL-120
Steel belt	Width:0.4m, Length 14m	Width:0.4m, Legnth 24mm	Width:0.6m,Length28m
Machine width	600mm	600mm	800mm
Machine length	7m	12m	14m
Size of mold	1.8-2.5 mm	1.8-2.5 mm	1.8-2.5 mm
Size of products	4-12mm (adjust)	4-12mm (adjust)	4-8mm (adjust)
Product's shape	hemispherical	hemispherical	hemispherical
Capacity	50-100kg/hour	100-300kg/h	400-600kg/h
Motor	5kw+1.5kw	5.5kw+1.5kw	4kw+1.5kw
Voltage	110v/220v/380v	110v/220v/380v	110v/220v/380v
Water pump	pressure: 0.3mpa water flow: 15-20 m3/h (equipped by user)	Flow quantity :20cbm/h	Flow quantity :35cbm/h

Detailed pictures

Feature

1. Granulator size can be choose between 4mm -12mm . Shapes can make granule, strip and flake
2.Equipment adopts frequency control, can choose a suitable speed according to the nature of the material
3.Product uniform particles, and beautiful, forming rate above 95%
4.Widely used van, melting point of material between 50 ℃ to 300 ℃, all can granulation forming, toxic materials can be closed.

Machine compose

1.Paraffin granulate distributing device
2.Stainless steel cooling tanks system
3.Frequency conversion electric control cabinet
4.Reducer transmission system
5.Stainless steel ALU-IND

Machine compose

6.Stainless steel valve
7.Sprayer , temperature probe
8.Stainless steel Rotary Steel Belt
9.Glue carbon steel conveyor roller
10.Complete frames and accessory

We have different models for different capacity. The mini customized type sales very well. It can be suitable small factory. We also have bigger capacity machine, can also customize for your request. Here are the detail informations.

Use scope

Sulfur, paraffin wax, petroleum resin, alcali sulphide, C5, C9 resin, resin C5C9 polymer resin; Asphalt, maleic anhydride, stearic acid, hot melt adhesive, rubber and plastic additives, antioxidant, antiager, all kinds of additives, etc

Package and on the delivery

Machine on the working

Final product be produced by this machine

Transaction list

Packaging & Shipping

Packing :

We send the machine picture which you order . then packing it with standard export wooden box after you confirm machine is ok .

Different machines package will different . we supply standard export wooden box ,carton box package . if big machine and production line machine it will be loaded in the container directly .

Delivery :

1.Delivery by sea :After delivery it to seaport . will tell you the shipping time and addrive time . Finally , send all origin documents to you by Express for free .

2.Delivery by Express to your door (DHL/TNT/Fedex/UPS etc ) or by air to your city airport .Will tell you the Express tracking number

3.Delivery to the warehouse which you reques . Will tell you

logistic or express tracking number

Our Services

Service before sale

Insist on quality first the production standard, every machine before leave the factory we test it ensure the quality is good.

Service on sale

We are confident that we sell our machines to customers at low prices and activated. Professionally

and patiently introduction

pictures and video to show machine

Service after sale

1, Free insurance for goods

2, 24 hours online to solve any

questions.Supply manual book

and technical support,maintain

video to help you.

FAQ

Questions/Answer

1,What is the voltage/phase for this machine ?

220V 50Hz/single phase ,380V 50Hz/three phase , 110V 60Hz/single phase also can made as

the clients’ need

2,What is the Mode of transportation ?

LCL and FCL by ship ,By Express (DHL,TNT, Fedex etc) ,By air

3,How long can we get the goods?

we usually delivery in 3-5 working days, we will inform you shipping time based on your seaport.

4,How long is the guarantee?

we promise guarantee as one year for non-human damage factor.

5,How should I do if meet some trouble while using?

we can supply English manual book and also take a video for showing how to resolve the problems

or dispatch our worker to your factory.

6,What about Payment term?

T/T(Telegraphic Transfer )-30% as prepayment by T/T, after seen the copy of the B/L sent by fax,

the balance of 70% should be effected . Western Union ,L/C ,Trade Assurance,Etc.

7,What’s your MOQ

1 set

8, How can i contact with you ?

You can send inquiry to me .

Aslo can contact with me by Cellphone/Wechat / Whatsapp /Viber: +86 15890126501

Skype: candy-yize,QQ: 2033530360

Our Qualification

Zhengzhou Yize Machinery CO.,Ltd’s factory was built in 2008, its exporting company was

assessed gold supplier in 2015 by alibaba. It is specialized in the production of Chemical machinery,

We will supply 100% QC inspection before shipment and 100% guaranteed after sales service.

Top quality machinery is waiting for your choose.
