Bread Packaging Machine Structure function:
1:Touching controller with person-machine interface, parameter enacted quickly, high speed and high efficiency
2:Adopting the tracing technology through photoelectricity, with digital input and sealing and cutting position nicely.
3:Diagnosing the troublesome and indicating to give an alarm
4:Constant-temperature adjusting, brainpower controlling and being suitable for all kinds of packaging materials.
5:Controlled by Double frequency conversion, the bag length can be cut with the enacting To finish by one step, saving time and saving film.
Model | GG-250B |
Film Width | Max. 350mm |
Bag length | 65-190 OR 90-330mm |
Bag width | 30～110mm |
Film Diameter | Max. 320mm |
Product height | Max.40mm |
Packing speed | 40～230 bags/min |
Power supply | 220V,50/60 H Z,2.6 KW |
Machine size | (L)3770X(W)670X(H)1450mm |
Machine weight | 880Kg |
Model | GG-250 |
Film Width | Max. 350mm |
Bag length | 90-220 OR 150-330mm |
Bag width | 30～110mm |
Film Diameter | Max. 320mm |
Product height | Max.55mm |
Packing speed | 40～230 bags/min |
Power supply | 220V,50/60 H Z,2.6 KW |
Machine size | (L)3770X(W)670X(H)1450mm |
Machine weight | 880Kg |
(Model) | GG-280 |
Width Of Packing Film | Max.280mm |
Length Of Bags | 90- or 150-330mm |
Width Of Bag | 50-140mm |
Product Height | Max.40mm |
Film Roll Diameter | Max.280mm |
Packaging Speed | 50-250bag/min |
Voltage Specification | 220V/50HZ |
Power Source Specification | 2.5kw |
Machine Dimensions | (L)4000×(W)950×(H)1450mm |
Machine Weight | 650Kg |
Note | Can match inflatable,code device |
Model | GGHQ-320 |
Packing speed | 30-180pcs/min |
Width of film | 90-360mm |
Making bag size | L100-320mm; W30-160mm; H5-55mm |
Total Power | 4.1kw |
Power supply | 1 Ph. AC220V, 50/60Hz |
Machine Size | L4000X W1050X H1650(mm) |
Net weight | 500kg |
Model | GG-400 |
Film Width | Max. 400mm |
Bag length | 180-440mm |
Bag width | 50-190mm |
Bag height | Max.60mm |
Film Diameter | Max. 320mm |
Packing speed | 40～230 bags/min |
Power supply | 110V/60 H Z,2.4 KW |
Machine size | (L)4020X(W)770X(H)1450mm |
Machine weight | 900Kg |
Model | GG-450 |
Film Width | Max. 450mm |
Bag length | 120-280mm |
Bag width | 60-200mm |
Bag height | Max.60mm |
Film Diameter | Max. 320mm |
Packing speed | 40～230 bags/min |
Power supply | 110V/60 H Z,2.4 KW |
Machine size | (L)4020X(W)720X(H)1320mm |
Machine weight | 900Kg |
Model | GG-600 |
Film width | Max .600mm |
Bag length | 200-600mm |
Bag width | 180-280mm |
Product height | Max 110mm |
Packing speed | 15-100bags/min |
Power supply | 220V,50/60 HZ ,2.8 KW |
Machine size | 4020*820*1320mm |
Machine weight | 850KG |
Main Parameters:
Using range: Automatic pillow packing machine is suitable for the solid object with regular form.
Such as biscuit, bread, sweet, commodities and industrial parts and so on.
The bulk cargos is put in a box and form a regular object, then to be packed.
