Elevator Access Control System Controller Board For 16 Floor

Description:

16-floors elevator access controller also known as smart card elevator access control system. It is used to lift hierarchical control, personnel up and down the elevator access control system products. It can be used to meet building service management company or management personnel access lift more efficient and safer management needs. The system set up by the addition of all the cardholder to enter the floor, carried out all floors access control. SA-EB16 status for different people with different floor privileges, you can specify a person who only can go to certain floors, certain floor or all floors, each floor through permissions management, there are some who can reach the floor, who can not reach some floors, and the controller may be authorized in accordance with time management.

1. Without the express elevator controller authorized offline operation,

2. An independent group of people can store 26,000 data records with 100,000 readers, so that all staffs have access to data recorded floor to be found.

3. And the elevator Max to 16 floors, but can be extended with an expansion board supports up to 16 expansion board, and ultimately can manage a maximum of 32 floors

4. Supports RS485 and TCP/IP communication methods.

5. Providing two standard card reader interface, supporting

6. WG26,WG34,WG44 reader or fingerprint device.

7. All input/output of elevator controller energized dynamic protection and all relay outputs With transient over-voltage protection, supports fire input linkage.

8. Automatically search for and install controller

9. Remote open door,full card to open door

10. Running stable monitoring(voltage input,watch dog,operating days)

11. Time frame management

12. Limit the number of people inside door and region

13. Fire protection alarm

14. Access authentication methods setting

15. Anti-passback, interlock function

16. Read card inside and outside to open door

17. Video capture
