commercial Weight sorting machine Weight sorting machinery Weight sorter machine
commercial Weight sorting machine Weight sorting machinery Weight sorter machine
FEATURES
1,New designed mechanical structure with IP65 Protection Grade, improving the measurement accuracy and speed
2,Mechanical designed to comply with food and pharmaceutical hygiene standards
3,Quick release drive unit for easy cleaning and maintenance
4,German precision load cell and high-speed weighing signal processing module, to ensure that the system is stable and accurate
5,50 products memory, quick product changeover
6,Intelligent parameter configuration, adjustedsortingsettings according to the productsize
7,Easy-to-use operatingsystem and HMI interface
8,Standard model machine can be sorted objects into 9 weighing zones
APPLICATIONIS
1. Online package weighing and sorting.
2. Applied to packing foods quality control.
3. Used to check unit product's weight whether meet target Object, and automatically reject sub-standard products.
Basic Info.
Model NO.: |
MN-220 |
Waterproof: |
IP 65 |
Belt Change System: |
Quick Belt Change System |
Weighing Range: |
10-1200g |
Lead Time: |
30 Workdays If No Stock |
Machine Frame: |
Stainless Steel 304 |
Warranty: |
One and Half Years, All Life Maintenance |
Operational Language: |
English (Other Language Can Be Optional) |
Conveyor Height: |
Can Be Done Based on Exact Requirement |
Control Panel: |
Color LCD Touch Screen |
Export Markets: |
Global |
Additional Info.
Trademark: |
Rehoo |
Packing: |
Wooden Case |
Standard: |
220V, 50HZ |
Origin: |
Shanghai, China |
HS Code: |
8423302000 |
Production Capacity: |
100sets/Year |
Technical Data | ||||
|
|
|||
Model |
MN-220 |
|||
Weighing Capacity |
10~1200g |
|||
Weighing Accuracy |
± 0.5g |
|||
|
Product dimensions |
L(mm) W(mm) H(mm) |
30~300 30~220 10~150 |
||
Weighing Scale Size |
400mm(L)x245mm(W) |
|||
Weigh Sensor |
Double-beam load cell |
|||
Conveying |
Food Belt(Belt Width:220mm) |
|||
Display |
Chinese, English |
|||
Minimum Scale |
0.1g |
|||
|
Setting Range |
Weight Value |
press the number keys:0.1g~1200.0g(standard +Over:0.1g difference) |
||
Belt speed |
Standard weight setting:15~60m/min(1m/min spacing) |
|||
Menu |
Standard/Over/Under weight, product name, belt speed etc pre-setting as one unit; Totally 50 units |
|||
Error Message display |
Zero error,photosensor error,setting error,products too close error,product too long error |
|||
IP rating |
In accordance with international IP65 standard |
|||
Construction |
304SUS, Polishing |
|||
|
Machine Size |
L x W |
750mm x 580mm |
||
The height from conveyor belt to the ground |
650mm~900mm |
|||
Machine Weight |
Appr.55Kg |
|||
Power Supply |
Single-Phase AC200V~240V
|
|||
