Latest 6YZ-230- hydraulic oil press with vacuum filter
Brief introduction of hydraulic oil press
Hydraulic Oil Press Machine, also knowed as sesame oil expeller, hydraulic oil press adopts hydraulic principle to produce pure and assured edible oil. The whole cooking oil expelling process is visible and needs only about 5-7 minutes; Sesame oil expeller is quite suitable to individual households and small oil mills in the countryside due to its little room occupancy and high pressing speed.It is available to sesame, walnut kernels, pumpkin seeds, kiwi seeds,tea seeds and almonds,etc.
Compared with other oil press, auto hydraulic oil press is the easiest one in operation, featured by highest oil yield and the wearing parts are most durable. The hydraulic oil press is widely used to produce oil from sesame seeds, peanuts, flax, rapeseed, sunflower seed, cotton seed, soybeans and other oil crop seeds. Hydraulic oil press is more suitable for household and small size plant
Feature &Advantage
1.Small size, covers small area, easy to learn, easy operation, no special requirement for the operator.
2.The machine is hydraulic oil press, with high pressure and high oil yield rate , the oil will be more clear.
3.The machine is fully automatic including the pre-heating system and pressure system.
4.It is made of stainless steel , so the oil can reach the healthy standard . Which is do good to people health.
5.The machine is applicable to the fixed-point processing and flow operation, convenient movement.
This machine mainly includes three parts:
1. main engine ,It is consisted of the floor, column ,top roof , pressing tang assembly ,
oil pan , nuts and other parts, virgin oil materials pressed in the tang assembly , the upward force from the cylinder assembly forward, oil flow from pressed tang cracks shed , the oil access pan to the oil tank.
2.hydraulic transmission system(with cooling system) Thigh oil yield of the main power source for the work , it is by shaft , worm gear , worm , gear pumps , high pressure pumps, pressure relief valve , manual valve , fuel tank assembly , pipe joints and other parts . This machine adopts the world's most advanced pump station , South Korea, three piston pump station ,compared to the domestic two piston,it has the low speed , oil pressure, stand the high temperature, oil temperature over the 65 degrees without cooling device can keep sustainable work.low temperature for oil need the cooling system.
3.electrical system the advanced part which consists of motor, voltage meter, temperature adjustment table , pressure gauge , power and insurance components, and other composition. It is the most advanced equipment which can replace of the manual operation of the sesame oil. This machine can press at least 2 to 7 kilograms per batch, the time is about 4 to 6 minutes, so it is very suitable for the citizens who live in the big and medium cities because they want get the high quality of oil of spending money. It is also can be used in the countryside, because the speed of oil pressing is fast so people can bring their oil raw material to press oil. In this way, they can be assured of the purity of their oil.
Main technical parameter
Models |
6YZ-180 |
6YZ-230 |
6YZ-320 |
External Dimension(mm) |
800*650*1100 |
900*750*1400 |
1100*1000*1500 |
Weight of machine |
530kg |
880kg |
1320kg |
Nominal pressure |
1600KN |
2200KN |
3000KN |
Max pressure for working |
55Mpa |
55Mpa |
55Mpa |
Power of electricity heating circle |
1KW |
1KW |
2KW |
Controlling temperature of heating circle |
70-100°C |
70-100°C |
70-100°C |
Sesame weight/time |
1-3kg |
2-7kg |
5-15kg |
Motor type sand power (kw) |
Y901-4-1.5kw |
Y901-4-1.5kw |
Y901-4-1.5kw |
