Help Center260 mm Vertical Type Electric Two Roller Wood Debarker With Factory Price
Related Products
-
Cheap Ring Type Log/wood Debarker/wood Debarking MachineUS$ 1,900 - 8,990MOQ: 1 Set -
Diesel Engine Wood Log Debarker Machine RussiaUS$ 100 - 6,900MOQ: 1 Set
-
Ring Type Mobile Log Debarker Single Roll Slot Debarker Diesel Wood DebarkerUS$ 100 - 6,900MOQ: 1 Set
-
Small Wood Debarker Tree Debarker/wood Debarking Machine in United StatesUS$ 1,900 - 8,990MOQ: 1 Set
-
Cheap Small Ring Type Log/wood Debarker/wood Debarking MachineUS$ 1,900 - 8,990MOQ: 1 Set
Brief information:
This wood skin peeling machine is suitable for most kinds of wood especially wood with
lots of fiber .The wood peeling machine is widely used in fiber board factory, paper mill, veneer
rotary cut factory, wood factory, pulp factory, wood storage plant, tree farm etc.
Features:
1,The wood skin peeling machine for sale is equipped with wheels, so it can move when working
in the forest.
2,This machine can process 40-320 mm.
3.The rate of barking is high, and almost won’t damage the wood.
4.It has a strong ability to barking when the log is not completely straight.
Specifications:
Model |
MNBP-150 |
MNBP-220 |
MNBP-260 |
MNBP-300 |
Max diameter |
150mm |
220mm |
260mm |
300mm |
Knife quantity |
4 |
4 |
4 |
4 |
Main power |
4.0kw |
4.0 kw |
5.5 kw |
5.5 kw |
Driving power |
1.5 kw |
1.5 kw |
1.5 kw |
1.5 kw |
Type 2
Horizontal type wood peeling machine:
This machine can be used to peel various kinds of wood especially wood with lots of fibers.
The diameter of the wood log could be 20-500mm.
It is applied to debark and treat fresh cut soft wood, some broad leaf wood, some frozen wood and dry wood. Wood with different spices, diameter, length, shapes can be processed by this machine.
Working principle:
1. Adopt the open bin, one end feeding, another end out material of a pipelined operation, to overcome the existing power cut feeding, discharging, segmented way of working shortcomings, high working efficiency.
2. As the teeth impact of wood segment, the wood doing circular movement within the housing, and the rotation around itself, so the peeling effect is high. On frozen wood, dry wood and hard skinned species also has a good peeling net rate.
3. Adaptability of wood, can be of different species, diameter, length and shape of the timber peeling. As the wood does rotary motion and the irregular beating, the bending log uneven part can be well touched with peeling tooth. So the net rate of bending wood peeling is much higher than other drum.
4. The housing is fixed, low energy consumption, low failure rate, maintenance workload is small, low vibration and noise, the machine can produce on the ground directly, even do not install the base, easy to operate.
Specifications:
Model |
MNBP-1 |
MNBP-2 |
Power |
7.5kw*2 |
7.5kw*2 |
Wood peeling diameter |
20-500mm |
20-500mm |
Production capacity |
5-8t/h |
8-10t/h |
Peeling rate |
More than 95% |
More than 98% |
