Factory price charcoal roasted coffee packing machine made in China coal bag BBQ BAGS shape bags
- 5000 Set / Sets per Month
- Qingdao shanghai port
- T/T Credit Card
- How Do You Make Charcoal Balls(0086-15978436639)
- Briquetting Plant Cost(86-15978436639)
- Production of Briquttes Briquetting Machine with a Capacity of 2t/h(86-15978436639)
- Briquette Machine for Mill Scale(86-15978436639)
- Briquette Machine for Iron Powder(0086-15978436639)
- Briquette Machine for Iron Fines(0086-15978436639)
Product Details
Brand Name: | Mona | Place of Origin: | Henan, China | Model Number: | 290 |
Certification: | CE ISO | After-sales Service Provided: | Engineers available to service machinery overseas | Warranty: | 1 Year |
Dimension(L*W*H): | 1.2*1.15*1.6m | Production Capacity: | 1-3t/h | Condition: | New |
Power(W): | 5.5kw | Motor Type: | AC Motor |
Product Description
Factory price coal bag BBQ BAGS shape bags charcoal roasted coffee packing machine made in China
Factory price coal bag BBQ BAGS shape bags charcoal roasted coffee packing machine made in China
Brief introduction:
(1). Production materials type: such as coal powder, charcoal powder, coconut shell
charcoal powder etc.
(2). Materials size required before feeding charcoal briquette machine: less than 3mm.
If the size is larger than 3mm, it is necessary to crush them into smaller size for briquetting.
(3). Moisture content: less than 15%.
(4).Shape of final product:The briquette shape can be round type,pillow shape,oval type,
bread shape and so on, which is widely used for :BBQ,barbecue,boiler,heating,metallurgy,
chemical,etc.
Remark:You can buy more roller with the machine,so the working time of charcoal briquette
machine is longer than before.
Features:
The roller is made by hard materials with good wear resistance and long life time.
The service life of wearing parts is up to 4000 hours.
The machines electricity coal reduce by 60%.
The machine is easy to operate and maintain.
The molding materials are energy saving, easy to tansport and higher utilization of waste.
The final products are smokeless, non-toxic, none peculiar and environmental protection.
The end outlet shape of products can be oval, round, square, ball egg-shaped and pillow shaped.
Working principle:
1. This charcoal ball press machine can press charcoal powder, charcoal dust, coal
powder, etc into round ball, oval ball or pillow-shaped charcoal.
2. This series of ball press machine will pass the power on to the two pressure roller through the reducer. The two sides and roll rotation, in both the rotating roll.
3. Natural materials to enter the ball roll mode, with the roll rotation, material pressure on a small become larger. When the material to the two rollers rotating
line contact point, the pressure of materials has reached the peak. Tremendous
pressure in the role of line, the materials becomes a finished product from the powder ball.
Main parameter of charcoal/coal ball extruder machine
Model | MN-290 | MN-360 | MN-450 | MN-600 |
Capacity | 1-2t/h for coal | 3-4t/h for coal | 5-8t/h | 10-12t/h |
0.5t/h for charcoal | 1t/h for charcoal | |||
Width of roller | 200mm | 250mm | 300mm | 336mm |
Dia of roller | 290 | 360 | 450 | 600 |
Power | 5.5kw | 7.5kw | 22kw | 30kw |
Dimension(m) | 1.2*1.15*1.6 | 1.3*1.15*2.05 | 1.45*1.55*1.85 | 2.35*2.15*2.7 |
Weight | 1t | 1.5t | 4.5t | 5.3t |
