Product Description Usage of wood pellet machine and cow feed pellet machine
1.For wood pellets use:
This series flat die pellet presses can be used for producing wood pellets and biomass pellets, too. Wood pellets are made of all kinds of Eucalyptus wood, birch, poplar ,wood waste. Biomass pellets are made of peanut shell,corn stalk and other biomass materials.
Description of flat die pellet machine granulator:
1. Make Wood Pellets for Biomass Fuel:
Advantages: Without dust ,smokeless, cleanliness. no CO, pollution-free.
High density and heat value, easy burn, low cost, convenient use.
Wood pellets production flow:
1. Crusher: crushing the wood materials into wood sawdust of <= 5mm size.
2. Dryer: drying wood sawdust moisture content about 10%-12%.
3. Pellet machine: make wood pellets, popular pellets diameter is 6mm 8mm 10mm.
4. Cooling machine: cool the high temperature down, then it can be kept for longer time.
5. Packing machine: pack the wood pellets to bags for easy transportation.
2.For Animal feed pellet use:
The compressed straw piece is suitable to be used as fuels and feedstuff of animals, such as horse, sheep, deer, pig, chicken, etc. Such machines are suitable for large farms, and organic herbal medicine and chemical industry etc.
2. Make Pellets for Animal Feed:
Advantages: Taste good, high-usage
Model |
MNPM-120 |
MNPM-150 |
MNPM-200 |
Power |
4 kw, 3 phase |
2.2 kw, single phase |
4 kw, 3 phase |
Capacity |
100-200 kg/h |
75-100 kg/h |
100-200 kg/h |
Pellets diameter |
4-6 mm |
4-6 mm |
4-6 mm |
Applicable materials |
rice husk, stalks, straw, etc. |
sawdust, corn, grain, wheat, etc. |
corn, grain, bean, wheat, etc. |
Pellets density |
1100-1200 kg/m3 |
1100-1200 kg/m3 |
1100-1200 kg/m3 |
Pellets moisture |
10 % |
10 % |
10 % |
Heating value |
4000-4500 Kcal |
4000-4500 Kcal |
4000-4500 Kcal |
Ash content |
8 % |
8 % |
8 % |
Use |
feed pellets, fuel pellets |
feed pellets, fuel pellets |
feed pellets, fuel pellets |
Rollers |
2, Die: 1 |
2, Die: 1 |
2, Die: 1 |
Pressure type |
flat die |
flat die |
flat die |
Weight |
80/100 kg |
80/100 kg |
95/115 kg |
mona series direct connection type pellet machine is manufactured with a special process, the machine processing of grain and smooth surface,
moderate hardness particles specifications are free to replace the adjustment. The feed particle internal curing high degree of both starch gelatinization,
protein coagulation degeneration, improve nutritional quality, easy digestion and absorption, but also kill the general pathogenic bacteria and parasites.
Through the mold compression ratio adjustment, you can reduce the temperature of the granulation to produce animal feed, organic fertilizer, fertilizer, bio-fertilizer and other low temperature materials, granulation.
The granulation natural cooled moisture is about 13%.
If you have questions, please call me I will provide you with better professional answer
